York AC048X1222 User Manual

036-21106-005 Rev. B (0505)
Unitary Products Group 5
- = Not applicable.
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER
COIL
1
MODEL
COOLING
MODEL
ELECTRIC
2
HEAT KW
W
RATED
CFM
TOTAL
CAPACITY
SENSIBLE
CAPACITY
SEER
W/O TXV
SEER
WITH TXV
3
EER
1 PH 12 SEER AC WITH N-AH / G2FD
AC018X1222
N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 600 19.6 13.2 12.50 12.50 11.60
AC024X1222
N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 750 23.6 16.9 12.00 12.00 11.00
N1AHB0806 2,5,8,10 17 G2FD030(S,H)17 750 24.0 17.3 12.00 12.00 11.10
AC030X1222
N1AHB1206 2,5,8,10 17 G2FD030(S,H)17 1000 30.0 21.3 12.00 12.00 11.00
N1AHB1206 2,5,8,10 17 G2FD036(S,H)17 1000 30.6 21.8 12.25 12.25 11.20
AC036X1222
N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 1200 33.8 23.6 11.50 11.50 10.70
N1AHB1206 5,8,10,15,19 17 G2FD046(S,H)17 1200 35.0 24.4 12.00 12.00 10.90
AC042X1221
N1AHC1606 5,8,10,15,20 21 G2FD042(S,H)21 1400 41.0 29.3 12.00 – 10.50
N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1400 42.5 30.6 12.00 – 10.75
AC048X1222
N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1575 46.5 36.0 12.20 12.20 10.90
N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1575 48.0 36.4 12.50 12.50 11.10
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1575 48.5 34.5 12.50 12.50 11.20
AC060X1223
N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24(T) 1800 56.5 43.4 – 12.00 10.10
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1800 56.5 43.8 – 12.00 10.15
1 PH 12 SEER AC / F2RP / RC / FC
4
,
5
AC018X1222
F2RC/F2FC024 5,8,10 18 – 600 20.0 13.2 12.50 12.50 11.70
F2RP/F2FP024 5,8,10 18 – 600 20.0 13.2 12.50 12.50 11.70
AC024X1222
F2RC/F2FC024 5,8,10 18 – 750 23.4 17.5 11.50 11.50 10.85
F2RC/F2FC030 5,8,10,15 18 – 750 23.4 17.5 11.50 11.50 10.85
F2RP/F2FP024 5,8,10 18 – 750 23.6 17.5 12.00 12.00 10.90
F2RP/F2FP030 5,8,10,15 18 – 750 24.0 17.9 12.00 12.00 11.10
AC030X1222
F2RC/F2FC030 5,8,10,15 18 – 1000 29.8 21.5 12.00 12.00 11.00
F2RC/F2FC036 5,8,10,15 21 – 1000 31.0 22.4 12.25 12.25 11.30
F2RP/F2FP030 5,8,10,15 18 – 1000 30.2 22.9 12.00 12.00 11.15
F2RP/F2FP036 5,8,10,15,19 21 – 1000 30.2 23.5 12.00 12.00 11.15
AC036X1222
F2RC/F2FC036 5,8,10,15 21 – 1200 34.6 26.2 12.00 12.00 10.85
F2RP/F2FP036 5,8,10,15,19 21 – 1200 34.6 26.2 12.00 12.00 10.85
F2RP/F2FP042 5,8,10,15 21 – 1200 34.8 26.3 11.60 11.60 10.70
F2FP048 5,8,10,15,20,25 24 – 1200 35.4 26.7 12.00 12.00 10.90
AC042X1221
F2RP/F2FP042 5,8,10,15 21 – 1400 40.5 28.9 11.80 – 10.35
F2FP048 5,8,10,15,20,25 24 – 1400 42.5 30.5 12.00 – 10.55
AC048X1222
F2FP048 5,8,10,15,20,25 24 – 1565 46.5 34.9 11.40 11.40 10.75
F2FP060 5,8,10,15,20,25 24 – 1575 48.0 35.9 11.50 11.50 10.70
AC060X1223
F2FP060 5,8,10,15,20,25 24 – 1800 56.0 42.0 – 12.00 10.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1 G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2 Single phase units require single phase 2HK heaters. Three phase units require three phase 2HK heaters.
3 TXV = Thermal Expansion Valve kit required. Use 1TV700 series kit.
4 To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC
. models. All ratings remain the same.
5 FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D (Blower on Delay) standard.
