York AM018M1021 User Manual

036-21573-001 Rev. A (0304)
Unitary Products Group 5
NOTES:
1. For condensing unit only. Does not include effect of evaporator motor power or heat.
2. Performance based on 15° superheat and 15° sub-cooling at condensing unit.
a. Increase capacity 1% for each 2° increase in sub-cooling.
b. Decrease capacity 1% for each 2° decrease in sub-cooling.
3. Sub-cooling in excess of 20° may result in excessively high condensing temperature with air on condenser above 115°F.
Maximum recommended condensing temperature is 140°F.
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE
1
COIL
MODEL
COOLING
CFM RANGE
(MIN.-MAX.)
WRATED CFM
NET MBH
SEER
W/O TXV
SEER + TXV
2
EER
TOTAL SENS.
AM012M1021
250
650
14,17 G1FA024S14,17 450 14.4 10.3 10.00 - 9.95
- G1HD024 450 14.6 10.4 10.00 - 10.00
17 G1NA024S17G 450 14.1 10.0 10.00 - 9.80
14,17 G1UA024S14,17 450 14.4 10.3 10.00 - 9.95
14,17 G2FD024(S,H)14,17 450 14.5 10.4 10.00 - 10.00
AM018M1021
575
725
14,17 G1FA024S14,17 650 18.3 13.3 10.00 - 9.40
- G1HD024 650 18.5 13.5 10.00 - 9.50
17 G1NA024S17G 650 17.7 12.4 10.00 - 9.50
14,17 G1UA024S14,17 650 18.3 13.3 10.00 - 9.40
14,17 G2FD024(S,H)14,17 650 18.6 13.4 10.00 - 9.50
AM024M1021
750
950
14,17 G1FA024S14,17 850 23.0 16.6 10.00 - 9.05
14 G1FA036S14 850 23.8 17.2 10.00 - 9.25
- G1HD024 850 23.6 17.0 10.00 - 9.25
17 G1NA030S17H 850 23.6 16.5 10.00 - 9.20
21 G1NA030S21B 850 23.6 16.5 10.00 - 9.20
14,17 G1UA024S14,17 850 23.0 16.6 10.00 - 9.05
14 G1UA036S14 850 23.8 17.2 10.00 - 9.25
14,17 G2FD024(S,H)14,17 850 23.4 16.8 10.00 - 9.15
AM030M1021
925
1175
14 G1FA030S14 1050 28.2 20.2 10.00 - 8.95
14 G1FA036S14 1050 28.2 20.2 10.00 - 8.95
17,21 G1FA036S17,21 1050 28.0 20.0 10.00 - 8.95
- G1HD036 1050 28.4 20.2 10.00 - 9.00
17 G1NA030S17K 1050 28.4 19.9 10.00 - 9.00
21 G1NA030S21M 1050 28.4 19.9 10.00 - 9.00
14 G1UA030S14 1050 28.2 20.2 10.00 - 8.95
14 G1UA036S14 1050 28.2 20.2 10.00 - 8.95
17,21 G1UA036S17,21 1050 28.0 20.0 10.00 - 8.95
17 G2FD030(S,H)17 1050 28.2 20.3 10.00 - 9.00
14 G2FD035(S,H)14 1050 28.0 20.0 10.00 - 8.95
1. Refer to Quick Selection Chart for specific furnace match-up.
2. TXV = Use 1TV700 Series Kit.
COOLING PERFORMANCE
MODEL
SUCT. T/P @
COMPR.
AIR TEMP ON CONDENSER
MODEL
SUCT. T/P @
COMPR.
AIR TEMP ON CONDENSER
75°F 95°F 115°F 75°F 95°F 115°F
TEMP. PSIG MBH KW MBH KW MBH KW TEMP. PSIG MBH KW MBH KW MBH KW
AM012M1021
35 61.5 13.1 1.01 11.6 1.20 10.1 1.40
AM024M1021
35 61.5 21.0 2.23 17.0 2.46 14.2 2.63
40 68.5 14.5 1.03 12.8 1.23 11.2 1.44 40 68.5 22.9 2.24 19.3 2.52 16.5 2.74
45 76.0 15.9 1.04 14.1 1.26 12.4 1.47 45 76.0 25.0 2.27 21.6 2.58 18.3 2.83
50 84.0 17.4 1.06 15.5 1.28 13.6 1.51 50 84.0 26.8 2.28 23.9 2.63 20.5 2.92
AM018M1021
35 61.5 16.2 1.66 13.1 1.84 11.0 1.96
AM030M1021
35 61.5 25.1 2.68 20.3 2.97 17.0 3.17
40 68.5 17.7 1.67 14.9 1.88 12.8 2.04 40 68.5 27.4 2.70 23.1 3.04 19.7 3.30
45 76.0 19.3 169 16.7 1.92 14.2 2.11 45 76.0 29.9 2.74 25.8 3.10 21.9 3.41
50 84.0 20.8 1.70 18.5 1.96 15.9 2.18 50 84.0 32.1 2.75 28.6 3.17 24.5 3.51
