036-21573-001 Rev. A (0304)
Unitary Products Group 7
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. AM012M1021
INDOOR COIL MODEL NO. G1NA024S17G
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 400 450 500
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75
T.C. 15.4 14.6 13.8 15.4 14.7 14.0 15.5 14.8 14.2
S.C. 9.6 9.6 9.2 10.0 9.9 9.7 10.3 10.3 10.2
K.W 1.21 1.21 1.21 1.23 1.22 1.22 1.25 1.24 1.24
85
T.C. 15.2 14.2 13.1 15.3 14.4 13.3 15.4 14.6 13.6
S.C. 9.8 9.5 9.0 10.1 10.0 9.5 10.5 10.4 10.1
K.W 1.32 1.31 1.31 1.34 1.33 1.33 1.36 1.35 1.35
95
T.C. 15.1 13.8 12.4 15.2 14.1 12.7 15.3 14.4 13.0
S.C. 9.9 9.5 8.8 10.3 10.0 9.3 10.7 10.5 9.9
K.W 1.43 1.42 1.42 1.45 1.44 1.44 1.47 1.46 1.46
105
T.C. 14.2 13.0 11.6 14.3 13.2 11.9 14.5 13.4 12.1
S.C. 9.5 9.0 8.3 10.0 9.6 8.8 10.5 10.1 9.4
K.W 1.56 1.55 1.53 1.58 1.57 1.55 1.60 1.59 1.57
115
T.C. 13.3 12.1 10.9 13.5 12.2 11.1 13.6 12.4 11.2
S.C. 9.2 8.6 7.7 9.8 9.1 8.3 10.4 9.7 8.9
K.W 1.69 1.67 1.65 1.71 1.70 1.67 1.73 1.72 1.69
125
T.C. 12.5 11.3 10.2 12.6 11.3 10.3 12.8 11.3 10.4
S.C. 8.8 8.1 7.2 9.5 8.7 7.8 10.2 9.2 8.4
K.W 1.82 1.80 1.76 1.84 1.82 1.78 1.86 1.85 1.81
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
N1AHB0806 G2FD024(S,H)17 1.03 1.04 1.01
F2RP018 1.03 1.06 1.04
G1FA024S14,17 1.02 1.03 1.01
G1HD024 1.04 1.04 1.01
G1UA024S14,17 1.02 1.03 1.01
G2FD024(S,H)14,17 1.03 1.04 1.01
