5
Assembly instructions
PREPARE YOUR WORK AREA - It is important you assemble the product in a clean and
uncluttered space.
WORK WITH A FRIEND - We recommend you have someone assist you with the assembly as
some of the components are quite heavy.
OPEN THE CARTON - Check any warnings on the carton and make sure you have it the right
way up.
UNPACK THE CARTON - BUT DO NOT TAKE TREADMILL OUT OF THE CARTON
• Removeallthepartsandpackagingfromabovethetreadmillandlaythemoutontheoor.
• Flattenthesidesofthecartonandremovetherestofthepackagingfromaroundthetreadmill.
Make sure you have the following parts:
A
x 4
ALLEN HEAD BOLT
(M8 X 45MM X 20MM)
MAIN FRAME
CONSOLE
LEFT UPRIGHT TUBE
RIGHT UPRIGHT TUBE
SAFETY KEY
SILICONE
B
x 4
ALLEN HEAD BOLT
(M8 X 15MM)
C
x 2
ALLEN HEAD BOLT
(M6 X 15MM)
D
x 4
PHILLIPS SCREW
E
x 1
T SHAPE
SIDE RAIL GUIDER
F
x 1
ALLEN KEY /
SCREW DRIVER
G
x 8
FLAT WASHER
H
x 8
SPRING WASHER
To Next Page
