Johnson Controls Unitary Products 9
5151060-YTG-F-1116
ELECTRICAL DATA FOR MULTI-SOURCE POWER SUPPLY: 208/230-1-60
Air Handlers
Models
Heater
Models
Heater
Amps
@240V
Min. Circuit Ampacity
MOP
1
208V 230V 208V 230V
Circuit Circuit
1st
3
2nd 3rd
1st
3
2nd 3rd
1st
3
2nd 3rd
1st
3
2nd 3rd
24B 6HK16501306 52 22.5 37.6 – 24.4 41.5 – 25 40 - 25 45 –
30B
6HK16501306 52 22.5 37.6 – 24.4 41.5 – 25 40 - 25 45 –
6HK16501506 60 25.4 43.3 – 27.6 47.9 – 30 45 - 30 50 –
36B
6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –
6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –
36C
6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –
6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –
42C
6HK16501306 52 25.0 37.6 – 26.4 41.5 – 25 40 – 30 45 –
6HK16501506 60 27.9 43.3 – 29.6 47.9 – 30 45 – 30 50 –
6HK16501806 72 45.3 39.0 – 48.8 43.1 – 50 40 – 50 45 –
6HK16502006 80 49.6 43.3 – 53.5 47.9 – 50 45 – 60 50 –
48C
6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –
6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –
6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –
48D
6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –
6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –
6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –
6HK16502506 100 52.5 43.3 21.7 56.7 47.9 24.0 60 45 25 60 50 25
60C
6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –
6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –
6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –
60D
6HK16501306 52 27.9 37.6 – 29.5 41.5 – 30 40 – 30 45 –
6HK16501506 60 30.8 43.3 – 32.7 47.9 – 35 45 – 35 50 –
6HK16501806 72 48.1 39.0 – 51.9 43.1 – 50 40 – 60 45 –
6HK16502006 80 52.5 43.3 – 56.7 47.9 – 60 45 – 60 50 –
6HK16502506 100 52.5 43.3 21.7 56.7 47.9 24.0 60 45 25 60 50 25
1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
