10 Johnson Controls Unitary Products
5151060-YTG-F-1116
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-3-60
Air Handler
Models
Heater Models
1
1. Asterisk (*) denotes the 20kW and 25kW heater models (6HK46502025 and 6HK46502525) come with service disconnects standard. Single source power
MCA and MOP requirements are given here only for reference if used with field installed single point power modification (S1-32436041000).
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity
MOP.
2
2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
208V 230V 208V 230V
18B 6HK36501025 23.1 28.8 31.3 30 35
24B 6HK36501025 23.1 28.8 31.3 30 35
30B
6HK36501025 23.1 28.8 31.3 30 35
6HK36501525 34.6 41.2 45.1 45 50
36B
6HK36501025 23.1 31.3 33.3 35 35
6HK36501525 34.6 43.7 47.1 45 50
6HK36501825 41.6 51.3 55.5 50 60
6HK46502025
*
46.2 56.3 61.0 60 70
36C
6HK36501025 23.1 31.3 33.3 35 35
6HK36501525 34.6 43.7 47.1 45 50
6HK36501825 41.6 51.3 55.5 55 60
6HK46502025
*
46.2 56.3 61.0 60 70
42C
6HK36501025 23.1 31.3 33.3 35 35
6HK36501525 34.6 43.7 47.1 45 50
6HK36501825 41.6 51.3 55.5 55 60
6HK46502025
*
46.2 56.3 61.0 60 70
48C
6HK36501025 23.1 34.2 36.4 35 40
6HK36501525 34.6 46.6 50.2 50 55
6HK36501825 41.6 54.2 58.6 55 60
6HK46502025
*
46.2 59.2 64.1 60 70
48D
6HK36501025 23.1 34.2 36.4 35 40
6HK36501525 34.6 46.6 50.2 50 55
6HK36501825 41.6 54.2 58.6 55 60
6HK46502025
*
46.2 59.2 64.1 60 70
6HK46502525
*
57.7 71.6 77.9 80 80
60C
6HK36501025 23.1 34.2 36.4 35 40
6HK36501525 34.6 46.6 50.2 50 55
6HK36501825 41.6 54.2 58.6 55 60
6HK46502025
*
46.2 59.2 64.1 60 70
60D
6HK36501025 23.1 34.2 36.4 35 40
6HK36501525 34.6 46.6 50.2 50 55
6HK36501825 41.6 54.2 58.6 55 60
6HK46502025
*
46.2 59.2 64.1 60 70
6HK46502525
*
57.7 71.6 77.9 80 80
