Johnson Controls Unitary Products 7
5151060-YTG-F-1116
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60
Air Handler Models
Heater Models
1,2
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity
MOP.
3
208V 230V 208V 230V
18B
6HK(0,1)6500206 10 14.6 15.6 15 20
6HK(0,1)6500506 20 25.4 27.5 30 30
6HK(0,1)6500806 32 38.6 42.2 40 45
6HK(0,1)6501006 40 47.0 51.5 50 60
24B
6HK(0,1)6500206 10 14.6 15.6 15 20
6HK(0,1)6500506 20 25.4 27.5 30 30
6HK(0,1)6500806 32 38.6 42.2 40 45
6HK(0,1)6501006 40 47.0 51.5 50 60
6HK(1,2)6501306 52 60.2 66.1 70 70
30B
6HK(0,1)6500206 10 14.6 15.6 15 20
6HK(0,1)6500506 20 25.4 27.5 30 30
6HK(0,1)6500806 32 38.6 42.2 40 45
6HK(0,1)6501006 40 47.0 51.5 50 60
6HK(1,2)6501306 52 60.2 66.1 70 70
6HK(1,2)6501506 60 68.7 75.4 70 80
36B
6HK(0,1)6500206 10 17.1 17.6 20 20
6HK(0,1)6500506 20 27.9 29.5 30 30
6HK(0,1)6500806 32 41.1 44.2 45 45
6HK(0,1)6501006 40 49.5 53.5 50 60
6HK(1,2)6501306 52 62.7 68.1 70 70
6HK(1,2)6501506 60 71.2 77.4 80 80
6HK(1,2)6501806 72 84.4 92.0 90 100
6HK(1,2)6502006 80 92.8 101.3 100 110
36C
6HK(0,1)6500206 10 17.1 17.6 20 20
6HK(0,1)6500506 20 27.9 29.5 30 30
6HK(0,1)6500806 32 41.1 44.2 45 45
6HK(0,1)6501006 40 49.5 53.5 50 60
6HK(1,2)6501306 52 62.7 68.1 70 70
6HK(1,2)6501506 60 71.2 77.4 80 80
6HK(1,2)6501806 72 84.4 92.0 90 100
6HK(1,2)6502006 80 92.8 101.3 100 110
42C
6HK(0,1)6500206 10 17.1 17.6 20 20
6HK(0,1)6500506 20 27.9 29.5 30 30
6HK(0,1)6500806 32 41.1 44.2 45 45
6HK(0,1)6501006 40 49.5 53.5 50 60
6HK(1,2)6501306 52 62.7 68.1 70 70
6HK(1,2)6501506 60 71.2 77.4 80 80
6HK(1,2)6501806 72 84.4 92.0 90 100
6HK(1,2)6502006 80 92.8 101.3 100 110
48C
6HK(0,1)6500206 10 19.9 20.7 25 25
6HK(0,1)6500506 20 30.8 32.7 35 35
6HK(0,1)6500806 32 44.0 47.3 45 50
6HK(0,1)6501006 40 52.4 56.6 60 60
6HK(1,2)6501306 52 65.6 71.3 70 80
6HK(1,2)6501506 60 74.0 80.5 80 90
6HK(1,2)6501806 72 87.3 95.2 90 100
6HK(1,2)6502006 80 95.7 104.4 100 110
For notes, see Page 8.
