036-21490-002-A-0204
Unitary Products Group 29
FIGURE 12 - FOUR AND SIX POINT LOADS - 15 TON
A
E
D
B
F
C
FRONT
A
B
C
D
FRONT
FIGURE 13 - FOUR AND SIX POINT LOADS - 20 TON
TABLE 20: FOUR AND SIX POINT LOADS
UNIT
4 - POINT LOADS (LBS)
TOTAL A B C D
180
2190
513
510 558 559
240
2840
495
925 925 495
NOTE: These weights are with economizer and 72 kW electric heat.
A
D
C
E
B
F
A
D
B
C
UNIT
6 - POINT LOADS (LBS)
TOTAL ABCDEF
180 2190 342 358 357 372 356 341
240 2840 330 330 473 617 617 473
NOTE: These weights are with economizer and 72 kW electric heat.
4 Point Loads
6 Point Loads
