York BQ240 User Manual

036-21489-001-C-1004
28 Unitary Products Group
FIGURE 10 : FOUR AND SIX POINT LOADS
A
E
D
B
F
C
FRONT
A
B
C
D
FRONT
TABLE 18: FOUR AND SIX POINT LOADS
UNIT
4 - POINT LOADS (LBS)
TOTAL ABCD
240
2390
514
538 684 654
NOTE: These weights are with economizer and 72 kW electric heat.
UNIT
6 - POINT LOADS (LBS)
TOTAL ABCDEF
240
2390
343
359 407 456 436 389
NOTE: These weights are with economizer and 72 kW electric heat.

York BQ240 Specifications

Power

voltage	208/230 V, 460 V, 575 V

Refrigerant Components

transformers capacity	75 VA
refrigerant circuits	dual
circuit breakers	24 V
