York CH060 User Manual

271846-YTG-B-0208
Johnson Controls Unitary Products
19
TABLE 17: DIMENSIONAL DATA - CU 5, 8, AND 10 TON VERTICAL MODELS
FIGURE 4 - DIMENSIONAL DATA - CU 5, 8, AND 10 TON VERTICAL MODELS
WATER OUT
WATER IN
CONDENSATE
DRAIN
COMPRESSOR/CONDENSER
ACCESS
G
C
F
0.63"
A
B
E
ELECTRICAL
PANEL
FAN MOTOR
ACCESS
FILTER ACCESS
COIL
FILTER
DRAIN
PAN
CONDENSATE
DRAIN
24.00"
D
SUPPLY
AIR
K
H
I
J
2.63"
OPTIONAL R/A
GRILLE
A B C D
RETURN AIR SUPPLY AIR
E F G H J K
CU060 26.00 72.00 42.00 23.00 20.00 4.00 34.00 12.25 14.88 13.50
CU096 29.00 82.00 64.00 27.00 25.00 4.00 56.00 14.75 24.63 15.88
CU120 29.00 82.00 64.00 27.00 25.00 4.00 56.00 14.75 24.63 15.88

York CH060 Specifications

General

Brand	York
Model	CH060
Category	Air Conditioner
Language	English
