271846-YTG-B-0208
6 Johnson Controls Unitary Products
NOTE: Cooling performance is rated at 80°F dry bulb 67°F wet bulb entering air temperature, CFM listed, 85°F entering
95°F leaving water temperature, and water flow rate listed. Gross capacity does not include the effect of evapora-
tor fan motor heat.
TABLE 2: GENERAL DATA CU 5-25 TON VERTICAL MODELS
Model - CU CU060A CU096A CU120A CU180A CU240A CU300
Nominal Cooling(Ton) 5 8 10 15 20 25
Cooling Performance
Gross Cooling Capacity(Btuh) 63300 100600 127800 188600 246800 322000
Design CFM 2000 3200 4000 6000 8000 10000
EER 12.5 13.2 12.5 12.0 11.6 11.5
Compressor-Type Scroll
Number Used 1 2 2 2 2 3
Evaporator Coil-Type Copper Tubes, Aluminum Fins
Face Area(sq ft) 5.00 9.37 10.50 15.11 19.00 19.79
Rows/FPI 3/12 3/12 3/13 3/12 3/14 4/12
Condenser-Type Coaxial
Number Used/Tons Capacity 1/5 2/4 2/5 2/7.5 2/10 3/7.5
Nominal Water flow rate (gpm) 15 24 30 45 60 78
Unit Water Connection Size 1" FPT 1-1/4" FPT 1-1/4" FPT 1-1/2" FPT 2" FPT 2" FPT
Evaporator Fan-Type Centrifugal, Forward Curved
Number Used 1 1 1 2 2 2
Diameter x Width (in) 12x9 15x12 15x12 15x9 15x11 15x11
Drive Adjustable Belt
Motor HP (Standard/Oversize) 1/1.5 1.5/2 2/3 3/5 5/7.5 7.5/10
Filters
Number Used-Size(in) 2-20x16x2 4-14x25x2 6-14x20x2 2-16x20x2
4-16x25x2
6-20x25x2 8-20x20x2
Condensate Drain Connection 3/4FPT
Weight
Shipping 625 815 975 1350 1525 1825
