OUTDOOR
TEMPERATURE,
°
F
SUPERHEAT AT SCROLL COMPRESSOR SUCTION,
°
F, AIRFLOW = 400 CFM/TON
INDOOR WB TEMPERATURE,
°
F
55 57 59 61 63 65 67 69 71 73 75
65 15.2 18.0 20.9 23.7 26.5 29.3 32.1 33.4 34.7 36.0 37.3
70 11.9 14.9 17.8 20.8 23.7 26.7 29.6 31.0 32.4 33.8 35.3
75 8.6 11.7 14.8 17.9 21.0 24.1 27.2 28.7 30.2 31.7 33.2
80 5.2 8.5 11.7 15.0 18.2 21.4 24.7 26.3 27.9 29.6 31.2
85 - 5.3 8.7 12.0 15.4 18.8 22.2 23.9 25.7 27.4 29.2
90 - 5.1 7.7 10.4 13.0 15.7 18.4 20.7 23.1 25.4 27.8
95 - - 6.8 8.7 10.6 12.6 14.5 17.5 20.4 23.4 26.3
100 - - 6.2 7.7 9.2 10.7 12.3 15.4 18.5 21.7 24.8
105 - - 5.6 6.7 7.8 8.9 10.0 13.4 16.7 20.0 23.3
110 - - - 5.6 6.4 7.1 7.8 11.3 14.8 18.3 21.8
115 -----5.25.59.212.916.620.4
TABLE 13
- SUPERHEAT CHARGING TABLE FOR MODEL 072
530.18-N7Y
Unitary Products Group 13
