Page #19 background image
Johnson Controls Unitary Products 19
923178-UTG-B-0114
When T
preset
+3.6°F< T
amb.
< T
preset
+41°F, the system con-
tinues to run normally
When 71.6°F<T
amb.
<78.8°F, the system continues to run
normally.
2. Protection – Auto Mode
When the system is running in cooling mode, the protec-
tions described in “Protection - Cooling Mode” apply.
When the system is running in heating mode, the protec-
tions described in “Protection – Heating Mode” apply.
When the ambient temperature changes, operation mode
will switch back and forth. Once the compressor is ener-
gized, it will keep running for a minimum of 6 minutes.
COMMON PROTECTION FUNCTIONS AND
FAULT DISPLAY UNDER COOL, HEAT, DRY
AND AUTO MODES
1. Overload Protection
Cooling Overload
When T
tube
126F, the system operates normally.
When T
tube
131F, compressor frequency is not
allowed to increase.
When T
tube
136F, compressor will run at reduced fre-
quency.
When T
tube
144F, compressor is de-energized and
the indoor fan will continue to run at preset speed.
Heating Overload
When T
tube
126F, the system operates normally.
When T
tube
131F, compressor frequency is not
allowed to increase.
When T
tube
136F, compressor will run at reduced fre-
quency.
When T
tube
144F, compressor is de-energized and
the indoor fan will continue to run for about 30 seconds
and stops.
2. High Discharge Temperature Compressor Protection
When compressor discharge temperature is 208 F, com-
pressor frequency is not allowed to increase.
When compressor discharge temperature is 217 F, com-
pressor will run at reduced frequency.
When compressor discharge temperature is 230 F, the
compressor will stop.
When compressor discharge temperature is 194 F and
the compressor has been idle for at least 3 minutes, it will
resume its operation.
3. Communication Fault
If the system fails to receive communication signals for more
than 3 minutes, its operation will stop.
4. Module Protection
Under module protection mode, the compressor will stop.
If the compressor remains idle for at least 3 minutes, it will
resume its operation.
If module protection occurs six consecutive times, the com-
pressor will not be allowed to start again.
5. Overload Protection
If the overload temperature is over 239 F, the compressor
will stop and the outdoor fan will stop after 30 seconds.
If the overload temperature drops below 203 F, the com-
pressor overload protection is reset.
If voltage on the DC bus is below 150V or over 420V, the
compressor will stop and the outdoor fan will stop after 30
seconds.
When voltage on the DC bus returns to its normal value
and the compressor has been idle for at least 3 minutes,
the compressor will resume its operation.
6. Temperature Sensors Faults.
Designation of Sensors Faults
Indoor ambient temperature The sensor is detected to be open-circuited or short-circuited for a continuous 30 seconds.
Indoor tube temperature The sensor is detected to be open-circuited or short-circuited for a continuous 30 seconds.
Outdoor ambient temperature The sensor is detected to be open-circuited or short-circuited for a continuous 30 seconds.
Outdoor tube temperature
The sensor is detected to be open-circuited or short-circuited for a continuous 30 seconds and no detection is
performed within 10 minutes after defrost begins.
Exhaust
After the compressor has operated for 3minutes, the sensor is detected to be open-circuited or short-circuited for a
continuous 30 seconds.
Overload
After the compressor has operated for 3minutes, the sensor is detected to be open-circuited or short-circuited for a
continuous 30 seconds.
