261660-YTG-D-0708
24 Johnson Controls Unitary Products
NOTE 1: HACR Type per NEC.
TABLE 19: DJ ELECTRICAL DATA WITHOUT POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL KW STAGES AMPS
180
(15)
208 22.4 164 2.1 15.4 0.0
None 0.0 ~ ~ 74.2 90
E18 13.5 1 37.5 74.2 90
E36 27.0 2 75.1 112.9 125
E54 40.6 2 112.6 160.1 175
E72 54.1 2 150.1 169.4 200
230 22.4 164 2.1 15.4 0.0
None 0.0 ~ ~ 73.2 90
E18 18.0 1 43.3 73.2 90
E36 36.0 2 86.6 126.3 150
E54 54.0 2 129.9 147.9 175
E72 72.0 2 173.2 191.2 225
460 10.9 100 1.1 7.2 0.0
None 0.0 ~ ~ 36.1 45
E18 18.0 1 21.7 36.1 45
E36 36.0 2 43.3 63.1 70
E54 54.0 2 65.0 74.0 90
E72 72.0 2 86.6 95.6 110
575 8.3 78 0.9 5.9 0.0
None 0.0 ~ ~ 28.2 35
E18 18.0 1 17.3 29.0 35
E36 36.0 2 34.6 50.7 60
E54 54.0 2 52.0 59.3 70
E72 72.0 2 69.3 76.7 90
210
(17 1/2)
208 25.6 190 2.1 20.0 0.0
None 0.0 ~ ~ 86.0 110
E18 13.5 1 37.5 86.0 110
E36 27.0 2 75.1 118.7 125
E54 40.6 2 112.6 165.9 175
E72 54.1 2 150.1 175.2 200
230 25.6 190 2.1 20.0 0.0
None 0.0 ~ ~ 86.0 110
E18 18.0 1 43.3 86.0 110
E36 36.0 2 86.6 133.3 150
E54 54.0 2 129.9 154.9 175
E72 72.0 2 173.2 198.2 225
460 12.8 95 1.1 10.0 0.0
None 0.0 ~ ~ 43.2 50
E18 18.0 1 21.7 43.2 50
E36 36.0 2 43.3 66.6 70
E54 54.0 2 65.0 77.5 90
E72 72.0 2 86.6 99.1 110
575 10.3 75 0.9 8.2 0.0
None 0.0 ~ ~ 35.0 45
E18 18.0 1 17.3 35.0 45
E36 36.0 2 34.6 53.6 60
E54 54.0 2 52.0 62.2 70
E72 72.0 2 69.3 79.5 90
