261660-YTG-D-0708
26 Johnson Controls Unitary Products
NOTE 1: HACR Type per NEC.
TABLE 20: DJ ELECTRICAL DATA WITH POWERED CONVENIENCE OUTLET
MODEL
(TON-
NAGE)
VOLTAGE
COMPRESSORS
OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION
MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR
1
SIZE
(AMPS)
RLA
EACH
LRA
EACH
MODEL
KW
STAGES AMPS
180
(15)
208 22.4 164 2.1 15.4 10.0
None 0.0 ~ ~ 84.2 100
E18 13.5 1 37.5 84.2 100
E36 27.0 2 75.1 125.4 150
E54 40.6 2 112.6 172.6 175
E72 54.1 2 150.1 181.9 200
230 22.4 164 2.1 15.4 10.0
None 0.0 ~ ~ 83.2 100
E18 18.0 1 43.3 84.6 100
E36 36.0 2 86.6 138.8 150
E54 54.0 2 129.9 160.4 175
E72 72.0 2 173.2 203.7 225
460 10.9 100 1.1 7.2 5.0
None 0.0 ~ ~ 41.1 50
E18 18.0 1 21.7 42.3 50
E36 36.0 2 43.3 69.4 70
E54 54.0 2 65.0 80.2 90
E72 72.0 2 86.6 101.9 110
575 8.3 78 0.9 5.9 4.0
None 0.0 ~ ~ 32.2 40
E18 18.0 1 17.3 34.0 40
E36 36.0 2 34.6 55.7 60
E54 54.0 2 52.0 64.3 70
E72 72.0 2 69.3 81.7 90
210
(17 1/2)
208 25.6 190 2.1 20.0 10.0
None 0.0 ~ ~ 96.0 110
E18 13.5 1 37.5 96.0 110
E36 27.0 2 75.1 131.2 150
E54 40.6 2 112.6 178.4 200
E72 54.1 2 150.1 187.7 200
230 25.6 190 2.1 20.0 10.0
None 0.0 ~ ~ 96.0 110
E18 18.0 1 43.3 96.0 110
E36 36.0 2 86.6 145.8 150
E54 54.0 2 129.9 167.4 175
E72 72.0 2 173.2 210.7 225
460 12.8 95 1.1 10.0 5.0
None 0.0 ~ ~ 48.2 60
E18 18.0 1 21.7 48.2 60
E36 36.0 2 43.3 72.9 80
E54 54.0 2 65.0 83.7 90
E72 72.0 2 86.6 105.4 110
575 10.3 75 0.9 8.2 4.0
None 0.0 ~ ~ 39.0 45
E18 18.0 1 17.3 39.0 45
E36 36.0 2 34.6 58.6 60
E54 54.0 2 52.0 67.2 70
E72 72.0 2 69.3 84.5 90
