282911-YIM-B-0807
10 Unitary Products Group
TABLE 7: PHYSICAL DATA
MODEL
DNH
030 036 042 048 060
EVAPORATOR
BLOWER
CENTRIFUGAL BLOWER (Dia. x W. in.) 10 X 8 11 x 10 11 x 10 12 x 11 12 x 11
FAN MOTOR HP (3 Speed) 1/2 3/4 3/4 3/4 1
EVAPORATOR
COIL
ROWS DEEP 3 3 3 3 3
FINS PER INCH 13 13 13 16 16
FACE AREA (Sq. Ft.) 3.5 3.5 4.5 4.5 4.5
CONDENSER
FAN
PROPELLER DIA. (in.) 22 22 22 22 22
FAN MOTOR HP 1/4 1/4 1/4 1/3 1/3
NOM. CFM TOTAL 2,400 2,400 2,400 3,000 3,000
CONDENSER
COIL
ROWS DEEP 1 2 1 2 2
FINS PER INCH 20 20 20 20 20
FACE AREA (Sq. Ft.) 11.7 11.7 14.7 14.7 14.7
CHARGE REFRIGERANT 22 (lbs./oz.) 4 / 9 6 / 12 5 / 14 8 / 0 8 / 12
FILTER FACE AREA (Sq. Ft.) Size (Nominal) 2.6/20x20 2.6/20x20
3.3/20x12
(2 Reqd.)
3.3/20x12
(2 Reqd.)
3.3/20x12
(2 Reqd.)
FURNACE
SECTION
NATURAL GAS BURNER ORIFICE NO.
(Drill Size)
43 43 40 40 40
PROPANE BURNER ORIFICE NO.
(Drill Size)
55 55 53 53 53
GAS CONNECTION SIZE
1/2
NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI
COMPRESSOR HERMETIC TYPE, (Qty. = 1) Scroll Scroll Scroll Scroll Scroll
TABLE 8: ELECTRICAL DATA
MODEL
DNH
POWER
SUPPLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR
COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS
2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
030 208/230-3-60 187 253 8.6 55 1.1 2.6 14.5 20 20 .96 75
030 460-3-60 414 504 4.3 27 0.6 1.4 7.4 15 15 .96 75
036 208/230-3-60 187 253 11.4 77 1.1 3.5 18.9 25 25 .96 75
036 460-3-60 414 504 5.7 39 0.6 1.8 9.5 15 15 .96 75
042 208/230-3-60 187 253 13.9 88 1.3 3.5 22.2 30 30 .96 75
042 460-3-60 414 504 6.4 44 0.7 1.8 10.5 15 15 .96 75
048 208/230-3-60 187 253 13.0 93 1.9 4.2 22.4 30 30 .96 75
048 460-3-60 414 504 6.4 46.5 1.0 2.1 11.1 15 15 .96 75
060 208/230-3-60 187 253 19.3 123 1.9 9.4 32.9 45 45 .96 75
060 460-3-60 414 504 10.0 62 1.0 4.7 16.0 20 20 .96 75
1.
Utilization range “A” in accordance with ARI Standard 110.
2.
Dual element, time delay type.
