FORM 100.50-EG1
7
YORK INTERNATIONAL
Physical Data
TABLE 1 – PHYSICAL DATA
MODEL SIZE 50 55 60 65
GENERAL DATA
Length (Inches) 336 336 336 336
Width (Inches) 92 92 92 92
Height (Inches) 82 82 82 82
Operating Weights (Lbs.) (base unit, no options)
Cooling Only (Rigging & Refrigerant) 8,080 8,290 8,530 8,740
Rigging Weights (Lbs.) (base unit, no options)
Cooling Only 8,010 8,210 8,440 8,640
Option Weights (Lbs.)
Power Exhaust (Blower, motor, fan skid & mod damper) 647 647 647 647
Power Exhaust (Blower, motor, fan skid, VFD & baro damper) 654 654 654 654
100% AMS (Measurement Station & Mounting) 110 110 110 110
25/75% AMS (Measurement Station & Mounting) 130 130 130 130
Min. AMS (Measurement Station & Mounting) 40 40 40 40
Barometric only 36 36 36 36
Condenser Hail Guard 32 32 32 32
Copper Condenser Coils 617 617 793 793
Copper Evaporator Coils 262 320 400 500
Roof Curb Weights (Lbs.)
14" Full Perimeter Roof Curb 787 787 787 787
14" Open Condenser Roof Curb 555 555 555 555
Compressor Data
Quantity / Size (Nominal Tons ) 4/13 4/13 4/15 4/15
Type Scroll Scroll Scroll Scroll
Capacity Steps (%) 25, 50, 75, 100 25, 50, 75, 100 25, 50, 75, 100 25, 50, 75, 100
Supply Fan and Drive
Quantity 1111
Type FC FC FC FC
Size 25-22 25-22 25-22 25-22
Motor Size Range (min. to max. HP) 7.5-40 7.5-40 7.5-40 7.5-40
Air Flow Range (min. to max. cfm) 10000-22500 12000-24000 14000-27000 14000-27000
Static Pressure Range (min. to max. ESP) 0-4" 0-4" 0-4" 0-4"
Exhaust Fan
Quantity 2222
Type FC FC FC FC
Size 15-15 15-15 15-15 15-15
Motor Size Range (min. to max. HP) 5-20 5-20 5-20 5-20
Air Flow Range (min. to max. cfm) 0-20000 0-20000 0-20000 0-20000
Static Pressure Range (min. to max. ESP) 0-1" 0-1" 0-1" 0-1"
Evaporator Coil
Size (square feet) 48.8 48.8 48.8 48.8
Number of rows/fins per inch 3/8 4/8 4/12 5/10
Tube Diameter/Surface 1/2"/enhanced 1/2"/enhanced 1/2"/enhanced 1/2"/enhanced
Condenser Coil (Aluminum Fins)
Size (square feet) 121.3 121.3 121.3 121.3
Number of rows/fins per inch 3/14 3/14 3/18 3/18
Tube Diameter 3/8" 3/8" 3/8" 3/8"
Condenser Coil (Copper Fins – Opt)
Size (square feet) 121.3 121.3 121.3 121.3
Number of rows/fins per inch 3/14 3/14 3/18 3/18
Tube Diameter 3/8" 3/8" 3/8" 3/8"
