Ref. Qty Part No. Part Description Ref. Qty Part No. Part Description
1 1 YKA00239b2 Main Frame (T ) 58 2 YKF60195b1 Hand Pulse Cable - Upper (850mm x 2pin)
2 1 YKA00195b2 Left Upright (T ) 59 2 YKF60196b1 Hand Pulse Cable - Lower (200mm x 2pin)
3 1 YKA00196b2 Right Upright (T ) 60 1 YKF60197b1 Computer Cable - Upper (900mm x 4pin)
4 1 YKA00197b2 Incline Frame (T) 61 1 YKF60198b1 Computer Cable - Mid (900mm x 4pin)
5 1 YKF50149c1 Incline Locking Rod (Ø13.8 x 610mm) 62 1 YKF60199b1 Computer Cable - Lower (500mm x 4pin)
6
2
YKP00211b2 Handlebar (T ) 63 2 YKF60200b1 Connect Cable (100mm)
7 1 YKA00198b2 Base Frame (T) 64 1 YKF60204b1 Connect Cable (100mm)
8 3 YKP00217b2 Deck Support Rail (12.7 x 38.1 x 548mm) 65 2 YKF60204b1 Connect Cable (100mm) - Earthing
9 1 YKA00199b2 Upright Brace Tube 66 2 YKF20334b3 Plastic Spacer (OD-22 x ID15 x 7mm)
10 1 YKP00218b2 Motor Bracket 67 1 YKF20335b3 Cable Funnel (Ø15 x 18 x 193mm)
11 1 YKP00200b2 Console Support & Handlebar (T ) 68 2 YKF20359b5 Connect Socket(Ø38x27mm)
12 1 YKP00201b2 Computer & Bottle Holder Mount Plate (192 x 690 x T-1.5mm) 69 1 YKF10381c1 Spring (Ø13.2 x 41mm)
13 2 YKA00200b2 Lower Lift support 70 1 YKF50153b5 Pull Plunger (M16 x 15 x 1.5mm)
14 1 YKP00202c1 Inner Slide Lift Support (21.21 x 357mm / T1.5mm) 71 2 YKF30047b1 Foam Strip (1050 x 15 x T-1.5mm)
15 1 YKF50150b6 Front Running Belt Roller/Pulley wheel (Ø42 x 523.5mm) 72 1 YKF20337b5 Square Flat Internal End Cap (SQ-21mm / 1.5mm tube)
16 1 YKF50151b6 Rear Running Belt Roller (Ø41.5 x 475mm) 73 1 YKF20012b5 Square Flat Internal End Cap (SQ-25.4mm / 1.5mm tube)
17 1 YKF30042b1 Foam Handgrip (Ø23 x 658 x T-4mm) 74 1 YKF20339b4 Oval Grommet/Cable Insert (14 x 20 x T10mm)
18 1 YKF50152b1 Running Deck (588 x 1120 x T-12mm) 75 1 YKF60202b1 Sensor & wire (18.5x30 x 220mm)
19 1 YKF40084b1 Running Belt (2505 x 400 x T-1.6mm) 76 2 YKF10382b6 Hex Head Bolt (M10 x 100mm)
20 1 YKF40080b1 Pulley Belt (483J-6) 77 1 YKF10383b6 Hex Head Bolt (M8 x 125mm)
21 2 YKF20318b4 Gromet (Ø22mm) 78 1 YKF10384b6 Carriage Bolt (M8 x 70mm)
22 2 YKF30052b1 Foam Handgrip (Ø30 x 680mm) 79 2 YKF10284b6 Round Allen Head Bolt (M8 x 45mm [6mm Allen])
23 2 YKF20319b3 Transport Wheel (Ø40 x 33mm) 80 4 YKF10385b6 Flat Allen Head Bolt (M8 x 42mm [6mm Allen])
24 1 YKF10379b5 Hand Knob - Female Fixing (M10 x 31mm) 81 1 YKF10386b6 Round Allen Head Bolt (M8 x 40mm [6mm Allen])
25 2 YKF30044b1 Non-Slip Foot Grip (80 x 400 x T-0.5mm) 82 1 YKF10387b6 Round Allen Head Bolt (M8 x 35mm [6mm Allen])
26 2 YKF20013b5 Square Flat Internal End Cap (SQ-38mm / 1.5mm tube) 83 10 YKF10062b6 Round Allen Head Bolt (M8 x 15mm [6mm Allen])
27 2 YKF50156b5 Hand Pulse Sensor 84 2 YKF10388b6 Countersunk Allen Head Self Tapping Screw (6 x 40mm [6mm Allen])
28 2 YKF20342b5 Bottle Holder (T ) 85 3 YKF10389b6 Cap Allen Head Bolt (M8 x 50mm [6mm Allen])
29 2 YKF30045b1 double-side tape (350 x 35 x 1.5mm) 86 2 YKF10375b6 Hex Head Bolt (M8 x 15mm)
30 12 YKF30046b1 Foam Pad (35 x 25 x T-2mm) 87 8 YKF10390b6 Countersunk Philips Head Self Drilling Screw (10 x 30mm)
31 2 YKF20320b5 Foot Rail (1016mm) 88 8 YKF10391b6 Round Flange Philips Head Self Tapping Screw (4 x 25mm)
32 1 YKF20321w5 Top Motor Cover (T ) (PU73338) 89 4 YKF10392b6 Round Flange Philips Head Self Tapping Screw (5 x 20mm)
33 1 YKF20322w5 Bottom Cover (T ) (PU73338) 90 30 YKF10393b6 Round Philips Head Self Tapping Screw (4 x 16mm)
34 1 YKF60239q27 Console/Computer - Top Assembly (PU73338) 91 10 YKF10394b6 Round Philips Head Machine Screw (M5 x 8mm)
35 1 YKF20323w5 Console/Computer - Bottom Cover (PU73338) 92 4 YKF10395b6 Round Philips Head Machine Screw (M4 x 8mm)
36 2 YKF20324w5 Cover - Handlebar (PU73338) 93 1 YKF10396b6 Hex Head Bolt (M4 x 25mm)
37 1 YKF20325w5 Rear Roller Guard - Left (PU73338) 94
2
YKF10417b6 Round Allen Head Bolt (M8x 95mm [6mm Allen])
38 1 YKF20326w5 Rear Roller Guard - Right (PU73338) 95 2 YKF10012b6 Nyloc Nut (M10)
39 4 YKF20327b3 Rubber Foot (Ø28 x Ø24 x 12.5mm) 96 7 YKF10061b6 Nyloc Nut (M8)
40 2 YKF20328b5 Round Plastic Bolt Cap (17mm Hex x OD-23.5 x 22mm) 97 4 YKF10401n1 Hex Nut (M4 x T-3.2mm)
41 1 YKF10431b6 Spring (Ø2.0xØ16.5x36.5mm) 98 3 YKF10397b6 Flat Washer (ID-10.5 x OD-21 x T-2mm)
42 1 YKF20329w5 Rear Left Endcap - Upper (T) (PU73338) 99 16 YKF10398b6 Flat Washer (ID-8.5 x OD-16 x T-1.5mm)
43 1 YKF20330w5 Rear Left Endcap - Lower (T) (PU73338) 100 2 YKF10399b6 Spring Washer (ID-8.5 x OD-16 x T1.5mm)
44 1 YKF20331w5 Rear Right Endcap - Upper (T) (PU73338) 101 1 YKF10402b6 E Clip (E12)
45 1 YKF20332w5 Rear Right Endcap - Lower (T) (PU73338) 102
2
YKF10422b6 Curved Washer (ID8.5 x OD16 x T1.5mm)
46 1 YKF60240 Drive Motor (1HP) 103 12 YKF10430b6 Star Washer (OD-15xID-8.5xT-0.7mm)
47 2 YKF20333b5 Round Internal / Semi External End Cap (tube size OD38.1mm) 104 6 YKF10403n1 Star Washer (ID-5.2 x 10 x T-1mm)
48 1 YKF60247 Ferite Core 105 8 YKF10404n1 Star Washer (ID-4.2 x 8 x T-1mm)
49 1 YKF60185b3 On/Off Rocker Switch 106 3 YKF20340w1 Cable Tie (3 x 190mm)
50 1 YKF60248b3 Circuit Breaker Module (10A) 107 2 YKF10405b6 Countersunk Philips Head Self Tapping Screw (4 x 20mm)
51 1 YKF60187b3 Power (Kettle) Socket 108 1 YKF20341b4 Round Grommet/Cable Insert (Ø16.5 x 11.5mm)
