036-21121-002 Rev. B (0103)
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 PHASE
ADDITIONAL R-22 CHARGE / ORIFICE SIZE FOR VARIOUS MATCHED SYSTEMS
Outdoor Unit
H1RA018S06 H1RA024S06 H2RA030S06 H2RA036S06 H1RA042S06 H1RA048S06 H3RA060S06
Unit Orifice (s)
1
51,53,55 59,61,63 67 71,73,75 75,78,81 78,81,84,87 96
Factory R-22 Charge, lbs-oz 3 - 6 3 - 11 3 - 14 3 - 15 5 - 4 7 - 5 6 - 2
Indoor Coil Coil Orifice
2
System Orifice - Additional Charge, Oz
G2FD024(S,H)14/176153 + 1459 + 6— ————
G2FD030(S,H)176553 + 23 59 + 867 + 3————
G2FD035(S,H)14 65 53 + 23 59 + 8 67 + 3 71 + 0 — — —
G2FD036(S,H)17 75 — 59 + 12 67 + 6 71 + 3 — — —
G2FD036(S,H)21 75 — — 69 + 9 71 + 3 — — —
G2FD042(S,H)21 78 — — — 71 + 7 75 + 1 — —
G2FD046(S,H)17 78 — — — 71 + 7 75 + 1 78 + 6 —
G2FD048(S,H)21/2478———— 75 + 981 + 15—
G2FD060(S,H)2490————78 + 1481 + 2096 + 6
G1HD024 59 55 + 6 61 + 1 — — — — —
G1HD036 69 — 63 + 7 67 + 7 73 + 9 — — —
G1HD048 81 — — — 73 + 15 78 + 8 78 + 9 —
G1HD060 93 — — — — — 81 + 16 96 + 1
G1FA/G1UA024S14/175955 + 359 + 0— ————
G1FA/G1UA030S146553 + 1459 + 665 + 0————
G1FA/G1UA036S14 73 — 59 + 4 67 +4 73 + 0 — — —
G1FA/G1UA03617/21 73 — 59 + 4 67 + 2 73 + 0 — — —
G1FA/G1UA048S17 84 — — — 75 + 11 75 + 1 81 + 13 —
G1FA/G1UA048S21 84 — — — 75 + 11 81 + 7 81 + 13 —
G1FA/G1UA060S24 90 — — — — 81 + 14 81 + 20 96 + 6
G1NA024S17G 5151 + 0— —————
G1NA030S17H 57—57 + 0—————
G1NA030S17K 63— —63 + 4————
G1NA030S21B 57—57 + 0 —————
G1NA030S21M 63——63 + 4————
G1NA036S17J 67———67 + 7———
G1NA036S21C 67———67 + 7———
G1NA048S21D 78————78 + 078 + 4—
G1NA048S24P 78————78 + 078 + 4—
G1NA060S24T 87 — — — — — — 96 + 0
G1NF024SOF 63 —
57 + 0
3
63 + 4
3
— ———
G1NF036SOF 67 — — —
67 + 7
3
———
G1NF048SOF 78————
78 + 0
3
78 + 4
3
—
G1NF060SOF 87——————96 + 11
F2RP/F2FP018 5351 + 0————— —
F2RC/F2FC024 6155 + 3——————
F2RP/F2FP024 6155 + 661 + 0—————
F2RP/F2FP030 65— 61 + 267 + 2————
F2RC/F2FC036 75 — — 71 + 0 — — —
F2RP/F2FP036 75 — — 67 + 8 73 + 4 — — —
F2RP/F2FP042 78 — — — 73 + 8 75 + 1 — —
F2FP048 84————73 + 8 87 + 6—
F2FP060 90————— 87 + 1096 + 6
FOOTNOTES:
1. These orifices are packed in the customer packet of each outdoor unit.
2. These orifices are factory mounted in the flow control device of each indoor coil.
3. Systems matched with furnaces or air handlers not equipped with blower-off delays, may require blower Time Delay Kit #6918A5011.
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaportor and for 15 feet of interconnecting line
tubing.
2. Verify the orifice size and additional charge required for specific evaportor coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaportor + adder for line set.
5. If the orifice in the evaportor was changed, verify the evaportor nameplate has been marked with the correct orifice size.
