GENERAL
These condensing units are designed for outdoor installation
on a roof or at ground level. Every unit is completely piped
and wired at the factory and is shipped ready for immediate
installation. Only the liquid and suction lines to the evaporator
coil, the filter drier, the control wiring and the main power
wiring are required to complete the installation. Each unit is
dehydrated, evacuated, leak tested and pressure tested at
450 psig before being pressurized with a holding charge of
Refrigerant-22 for shipment and/or storage.
All controls are located in the front of the unit and are readily
accessible for maintenance, adjustment and service. All
wiring (power and control) can be made through the front of
the unit.
REFERENCE
This instruction covers the installation and operation of the
basic condensing unit. For refrigerant piping installation refer
to document 247077 “Application Data-General Piping Rec
-
ommendations for Split Systems Air Conditioners and Heat
Pumps”.
RENEWAL PARTS
Contact your local York
®
parts distribution center for autho-
rized replacement parts for this equipment.
INSPECTION
As soon as a unit is received, it should be inspected for possi-
ble damage during transit. If damage is evident, the extent of
the damage should be noted on the carrier's freight bill. A
separate request for inspection by the carrier's agent should
be made in writing.
INSTALLATION
LIMITATIONS
These units must be installed in accordance with all national
and local safety codes. If no local codes apply, installation
must conform to the appropriate national codes. See Table
1
for Unit Application Data. Units are designed to meet National
Safety Code Standards. If components are to be added to a
unit to meet local codes, they are to be installed at the
dealer's and/or the customer's expense.
NOMENCLATURE
PRODUCT IDENTIFIER
CE = Condensing Section
VOLTAGE CODE
FACTORY INSTALLED HEAT
A = Not Applicable
50 = 380/415-3-50
150 = 12.5 Tons (43.9 kW)
180 = 15 Tons (52.7 kW)
240 = 20 Tons (70.2 kW)
NOMINAL COOLING
CAPACITY
PRODUCT GENERATION
5 = 5th Generation
PRODUCT CATEGORY
H = Split-System Condensing Unit
H
5
C
E
1
8
0
A
5
0
