SERVICE VALVES
These condensing units have service valves on the compres-
sor suction line and on the liquid line leaving the condenser
coil.
The liquid and suction line service valves are shipped from
the factory front-seated and closed with the valve stem in the
maximum clockwise position.
Start the compressor (after 8 hours of crankcase heat) and
continue to charge refrigerant gas through the access port on
the suction service valve until the correct charge is installed.
TABLE 8: CONDENSING UNIT ONLY COOLING CAPACITIES AND POWER REQUIREMENTS
Model
Compressor Suction Ambient Temp. Entering Condenser Coil (°C)
Pressure
(KPA)
Saturated
Temp. (°C)
20 25 30 35 40 45 50
kW
1
(thermal)
kW
2
(input)
kW
(thermal)
kW
(input)
kW
(thermal)
kW
(input)
kW
(thermal)
kW
(input)
kW
(thermal)
kW
(input)
kW
(thermal)
kW
(input)
kW
(thermal)
kW
(input)
150
365 -2 40 9.9 38 10.8
37
11.7 35 12.8 33 14 31 15.4 29 17
413 1 44 10.1 42 11 40 11.9 38 13 36 14.3 34 15.6 32 17.2
465 4 48 10.3 46 11.1 44 12.1 42 13.2 40 14.5 37 15.9 35 17.4
520 7 52 10.5 50 11.4 48 12.3 46 13.4 43 14.7 41 16.1 39 17.7
580 10 57 10.8 54 11.6 52 12.6 49 13.7 47 15 45 16.4 42 18
180
365 -2 60 14.3 57 15.6 54 17.0 52 18.5 49 20.2 46 22.0 42 24.1
413 1 66 14.6 63 15.9 60 17.3 57 18.8 53 20.6 50 22.4 46 24.4
465 4 72 14.9 69 16.1 65 17.6 62 19.2 58 20.9 55 22.8 50 24.8
520 7 78 15.2 74 16.4 71 17.9 67 19.5 64 21.3 60 23.2 55 25.2
580 10 84 15.5 81 16.8 77 18.2 73 19.8 69 21.6 65 23.6 60 25.6
240
365 -2 66 17.2 74 18.4 61 19.9 58 21.6 54 23.4 52 25.5 49 27.8
413 1 74 17.4 70 18.6 67 20.1 64 21.7 60 23.6 57 25.6 53 28.1
465 4 81 17.6 77 18.8 73 20.2 70 21.9 66 23.8 62 25.9 59 28.2
520 7 88 17.8 84 19 80 20.4 76 22.1 72 24 68 26.1 64 28.5
580 10 96 18.1 92 19.2 88 20.6 83 22.3 79 24.2 74 26.3 70 28.7
1.
Capacities are gross ratings.
2.
Power is for the condensing unit only.
Never operate the compressor while under a deep
vacuum.
Do not attempt to start the compressor without at
least 8 hours of crankcase heat or compressor
damage can occur.
