292424-XIM-A-0307
6 Unitary Products Group
Refer to Figure 3 for typical field wiring.
CONTROL WIRING
Refer to Figure 4 for the location of the control wire access
opening through the front of the unit.
Route the necessary low voltage control wires (18 AWG/
1.0mm
2
min.) from the Simplicity
®
Control Board through this
access opening to the room thermostat and to the evaporator
blower motor controller.
The room thermostat should be located on an inside wall
approximately 56"(1422mm) above the floor where it will not
be subject to drafts, sun exposure or heat from electrical fix-
tures or appliances. Follow manufacturer's instructions
enclosed with thermostat for general installation procedure.
Refer to Figure 3 for typical field wiring.
TABLE 3: PHYSICAL DATA
Model
Size
(Mbh)
Compressor
1
1.
Compressor set consists of two Copeland scroll compressors manifolded into a single refrigerant circuit.
Condenser
Unit Weight
lbs. (Kg.)
Charge,
(Refrigerant-22)
Lbs.-Oz./Kg.
24” Fan (Propeller)
Fan Motor
2
2.
The ball bearing, 48 frame, single phase condenser fan motor have internal protection are directly connected to the condenser
fans. Motor rotation is counterclockwise when viewing the lead end, which is opposite the shaft end.
Coil
Rating
(Tons)
Cap.
(Stg’s)
Qty.
Blades/
Pitch
Deg.
Nom.
CFM
M
3
/Sec.
Qty. Hp/kW RPM Rotation
Fins
per
inch
Rows
Deep
Ship Oper.
Holding
3
3.
Holding charge is the amount in the unit as shipped from the factory.
Oper.
4
4.
Operating refrigerant charge is for the condensing unit and the matching York air handler, but does not include the charge in the
interconnecting piping.
150 12.5 2 2 4/38 9000/4.2 2 1/.75 950 CCWLE 20 2 920(417) 940(429) 1 - 0 21-10/9.8
180 15 2 2 3/34 13000/6.1 2 1/.75 1250 CCWLE 20 2 970(440) 990(449) 1 - 0 28-4/12.9
240 20 2 2 3/34 12800/6.0 2 1/.75 1250 CCWLE 20 2 992(450) 1012(459) 1 - 0 30-5/13.7
