York PCG4B48 User Manual

5005562-YTG-A-0215
Johnson Controls Unitary Products 7
COOLING PERFORMANCE DATA
PACKAGED UNIT MODEL NO. PCG4A24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1000 800 600
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 30.0 33.4 33.4 36.7 39.8 27.4 30.9 31.2 34.3 37.6 24.9 28.4 29.0 31.8 35.4
S.C. 30.0 28.6 23.8 23.7 18.7 27.4 25.0 20.9 21.0 16.9 24.9 21.3 18.1 18.2 15.1
K.W. 1.48 1.47 1.47 1.46 1.44 1.44 1.44 1.44 1.42 1.40 1.41 1.41 1.40 1.39 1.37
65 / 55
T.C. 25.9 29.1 28.8 32.1 35.4 25.9 28.7 28.7 31.9 35.4 25.9 28.4 28.6 31.6 35.3
S.C. 25.6 23.6 19.9 19.9 16.0 25.7 23.6 19.7 19.8 16.0 25.9 23.5 19.5 19.7 16.0
K.W. 1.57 1.58 1.57 1.57 1.56 1.58 1.58 1.58 1.54 1.53 1.59 1.59 1.59 1.50 1.49
75 / 63
T.C. 26.9 28.4 28.2 31.4 35.3 24.4 26.6 26.2 29.4 33.2 21.9 24.8 24.2 27.5 31.1
S.C. 26.9 25.8 20.9 21.1 16.8 24.0 22.2 18.5 18.6 15.1 21.2 18.6 16.0 16.1 13.3
K.W. 1.77 1.78 1.78 1.62 1.61 1.72 1.73 1.73 1.65 1.65 1.66 1.68 1.67 1.69 1.69
85 / 69
T.C. 22.0 23.8 23.4 26.5 29.9 22.3 24.1 23.7 26.8 30.2 22.6 24.4 24.1 27.2 30.5
S.C. 21.7 20.6 17.1 17.4 13.7 22.1 20.9 17.2 17.5 13.8 22.5 21.1 17.3 17.5 13.9
K.W. 1.86 1.87 1.87 1.89 1.95 1.85 1.86 1.86 1.84 1.88 1.84 1.86 1.86 1.79 1.81
95 / 75
T.C. 22.1 22.8 22.5 25.5 28.8 20.2 21.6 21.3 24.2 27.3 18.3 20.3 20.1 22.9 25.8
S.C. 22.1 22.7 18.3 18.8 14.1 20.1 19.5 16.0 16.4 12.6 18.2 16.4 13.6 14.0 11.1
K.W. 2.07 2.07 2.06 2.09 2.21 1.98 2.00 2.00 2.03 2.11 1.90 1.94 1.94 1.97 2.00
105 / 83
T.C. 19.3 19.9 19.2 22.0 24.7 17.8 18.8 18.3 21.0 23.7 16.3 17.7 17.3 20.0 22.7
S.C. 19.3 19.8 16.4 17.2 11.9 17.8 17.4 14.4 14.9 10.8 16.2 15.1 12.4 12.7 9.8
K.W. 2.21 2.21 2.20 2.24 2.34 2.12 2.13 2.12 2.17 2.25 2.03 2.06 2.05 2.11 2.15
115 / 89
T.C. 16.6 17.0 16.0 18.5 20.7 15.5 16.1 15.4 17.9 20.2 14.3 15.1 14.7 17.3 19.7
S.C. 16.6 17.0 14.6 15.6 9.6 15.4 15.4 12.9 13.6 9.1 14.3 13.8 11.1 11.5 8.6
K.W. 2.36 2.35 2.32 2.38 2.47 2.25 2.26 2.24 2.31 2.38 2.15 2.17 2.17 2.24 2.30
125 / 95
T.C. 13.9 14.1 12.8 15.1 17.6 13.1 13.4 12.4 14.8 17.2 12.3 12.6 12.0 14.5 16.7
S.C. 13.9 14.1 12.8 14.0 9.4 13.1 13.4 11.4 12.2 8.4 12.3 12.6 9.9 10.3 7.4
K.W. 2.50 2.49 2.45 2.53 2.59 2.39 2.39 2.36 2.45 2.52 2.27 2.29 2.28 2.37 2.45
COOLING PERFORMANCE DATA
PACKAGED UNIT MODEL NO. PCG4A30
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1200 1000 800
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 41.0 43.6 43.2 44.9 48.3 37.8 41.0 40.8 43.8 47.9 34.5 38.4 38.5 42.8 47.5
S.C. 40.2 38.5 32.6 31.1 24.5 36.9 34.5 29.5 28.8 23.6 33.6 30.5 26.4 26.5 22.6
K.W. 1.71 1.71 1.71 1.68 1.66 1.67 1.66 1.65 1.65 1.62 1.62 1.61 1.60 1.61 1.59
65 / 55
T.C. 37.4 40.0 38.8 41.6 45.6 34.4 37.6 36.9 40.5 44.1 31.4 35.2 35.1 39.4 42.6
S.C. 37.0 36.3 30.5 29.8 23.4 34.0 32.5 27.6 27.3 25.2 31.0 28.7 24.6 24.8 27.0
K.W. 1.88 1.89 1.89 1.88 1.86 1.83 1.83 1.83 1.83 1.82 1.78 1.77 1.78 1.78 1.78
75 / 63
T.C. 33.8 36.4 34.3 38.3 42.9 31.1 34.1 33.0 37.1 40.3 28.4 31.9 31.7 36.0 37.7
S.C. 33.8 34.2 28.4 28.5 22.3 31.1 30.5 25.6 25.8 26.9 28.4 26.9 22.8 23.2 31.5
K.W. 2.04 2.06 2.08 2.08 2.06 1.99 2.00 2.02 2.02 2.02 1.94 1.93 1.95 1.95 1.97
85 / 69
T.C. 30.1 32.3 29.8 34.2 38.6 27.8 30.3 28.8 33.2 36.6 25.5 28.2 27.7 32.1 34.5
S.C. 30.1 31.2 26.1 26.7 20.6 27.8 28.1 23.4 24.0 21.9 25.5 25.0 20.8 21.3 23.3
K.W. 2.22 2.23 2.24 2.27 2.27 2.15 2.16 2.14 2.19 2.22 2.09 2.08 2.03 2.12 2.16
95 / 75
T.C. 26.3 28.3 25.3 30.1 34.3 24.4 26.4 24.5 29.2 32.8 22.6 24.6 23.7 28.2 31.3
S.C. 26.3 28.3 23.7 24.8 18.9 24.4 25.7 21.2 22.2 17.0 22.6 23.1 18.7 19.5 15.1
K.W. 2.39 2.39 2.41 2.45 2.47 2.32 2.31 2.26 2.37 2.41 2.24 2.24 2.11 2.30 2.35
105 / 83
T.C. 21.4 24.8 20.6 25.9 28.7 20.3 22.8 20.0 24.7 27.8 19.2 20.8 19.4 23.4 26.9
S.C. 21.4 24.8 19.5 22.4 16.9 20.3 22.3 17.8 20.0 15.2 19.2 19.9 16.1 17.5 13.6
K.W. 2.57 2.57 2.56 2.61 2.67 2.49 2.49 2.44 2.50 2.61 2.41 2.40 2.32 2.38 2.55
115 / 89
T.C. 16.7 21.3 16.0 21.8 23.3 16.3 19.3 15.6 20.3 23.0 15.9 17.2 15.2 18.8 22.7
S.C. 16.7 21.3 15.5 20.1 14.9 16.3 19.0 14.5 17.8 13.5 15.9 16.7 13.6 15.6 12.0
K.W. 2.74 2.74 2.71 2.77 2.86 2.66 2.65 2.61 2.62 2.80 2.57 2.56 2.52 2.46 2.73
125 / 95
T.C. 12.0 17.9 11.4 17.7 17.8 12.3 15.7 11.2 15.9 18.2 12.6 13.6 11.0 14.1 18.5
S.C. 12.0 17.9 11.4 17.7 13.0 12.3 15.7 11.2 15.7 11.7 12.6 13.6 11.0 13.7 10.5
K.W. 2.91 2.91 2.86 2.92 3.06 2.83 2.82 2.79 2.73 2.99 2.74 2.72 2.72 2.55 2.92
