TABLE 2: DH PHYSICAL DATA
Component
Models
078 090 102 120 150
Evaporator
Blower
Blower, Centrifugal
(Dia. X Wd. in.)
12 x 12 12 x 12 12 X 12 15 x 15 15 x 15
Motor, Standard (HP)
1-1/2 2 3 2 3
Motor, Optional (HP)
2 33 3 5
Evaporator
Coil
Rows
3 33 4 4
Fins per Inch
15 15 15 15 15
Height (in.)
32 32 32 40 40
Face Area (ft.
2
each)
10.67 10.67 10.67 13.2 13.2
Condenser
Fan
(2 per Unit)
Propeller Dia.
(in., each)
24 24 24 24 24
Motor (HP, each)
1/3 1/3 1/3 3/4 3/4
CFM, Nominal (each)
3400 3400 3400 4400 4400
Condenser
Coil
(2 per unit)
Rows (each)
Sys 1: 2 Row
22 2 2
Sys 2: 1 Row
Fins per Inch
20 20 20 20 20
Height (in., each)
36 36 36 44 44
Face Area (ft.
2
each)
12 12 12 14.5 14.5
Refrigerant
Charge
System 1 (lb./oz.)
8/0 8/12 9/8 12/0 9/14
System 2 (lb./oz.)
4/12 9/0 8/2 11/0 9/4
Compressors
Quantity
2 22 2 2
Type
Recip. Recip Recip. Recip Scroll
Air Filters
Size (Wd. x Ht. x
Thickness in.)
25x16x2 25x16x2 25x16x2 25x20x2 25x20x2
Number Per Unit
4 44 4 4
