York PREDATOR 102 User Manual

246646-YTG-C-0606
Unitary Products Group 15
TABLE 7: COOLING CAPACITY DH102 (8-1/2 TON) UNIT
Air On
Evap. Coil
Temperature of Air on Condenser Coil 75°F Temperature of Air on Condenser Coil 85°F
CFM
WB
(°F)
Tot.
Cap.
1
(MBH)
Tot.
Input
2
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
Tot.
Cap.
1
(MBH)
Tot.
Input
2
(kW)
Sensible Capacity (MBH)
*
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
2550
72 117.0 1.8 66.8 59.5 52.2 44.9 37.7 - - 112.5 7.6 64.3 57.0 49.8 42.5 35.2 - -
67 112.1 1.9 85.1 77.8 70.5 63.2 56.0 48.7 41.4 106.1 7.5 82.2 74.9 67.7 60.4 53.1 45.8 38.6
62 104.1 2.0 104. 99.2 92.0 84.7 77.4 70.2 62.9 98.1 7.4 98.1 93.4 86.1 78.8 71.6 64.3 57.0
57 104.5 1.9 104. 103. 96.0 88.7 81.5 74.2 66.9 97.5 7.4 97.5 96.7 89.4 82.2 74.9 67.6 60.4
2975
72 120.7 4.3 72.7 64.1 55.5 46.9 38.3 - - 116.0 7.6 70.5 61.9 53.3 44.7 36.1 - -
67 115.7 4.3 92.1 83.5 75.0 66.4 57.8 49.2 40.6 109.4 7.5 89.6 81.0 72.4 63.9 55.3 46.7 38.1
62 107.5 4.4 107. 105. 97.8 89.2 80.6 72.0 63.4 101.1 7.4 101. 98.8 92.2 83.6 75.0 66.4 57.8
57 107.8 4.4 107. 107. 102. 93.5 84.9 76.3 67.7 100.6 7.4 100. 100. 95.8 87.2 78.6 70.0 61.4
3400
72 124.5 6.8 78.6 68.7 58.8 48.9 39.0 - - 119.6 7.6 76.6 66.7 56.8 46.9 37.0 - -
67 119.3 6.8 99.2 89.3 79.4 69.5 59.6 49.6 39.7 112.7 7.5 97.1 87.1 77.2 67.3 57.4 47.5 37.6
62 110.8 6.9 110. 110. 103. 93.7 83.8 73.9 63.9 104.2 7.4 104. 104. 98.3 88.4 78.5 68.6 58.6
57 111.2 6.8 111. 111. 108. 98.3 88.3 78.4 68.5 103.7 7.4 103. 103. 102. 92.2 82.3 72.4 62.4
3825
72 125.4 6.9 83.4 72.2 60.9 49.6 38.3 - - 120.8 7.7 81.8 70.5 59.2 47.9 36.6 - -
67 120.2 6.9 104. 93.5 82.2 70.9 59.6 48.3 37.0 113.9 7.6 103. 91.8 80.5 69.2 57.9 46.6 35.4
62 111.6 6.9 111. 111. 108. 96.7 85.4 74.1 62.8 105.3 7.5 105. 105. 102. 91.1 79.8 68.5 57.2
57 112.0 6.9 112. 112. 110. 99.2 87.9 76.6 65.3 104.7 7.5 104. 104. 104. 92.7 81.4 70.1 58.8
4250
72 126.3 6.9 88.3 75.6 62.9 50.3 37.6 - - 122.1 7.7 87.0 74.3 61.6 49.0 36.3 - -
67 121.0 6.9 110. 97.6 85.0 72.3 59.6 46.9 34.3 115.1 7.6 109. 96.5 83.8 71.1 58.5 45.8 33.1
62 112.4 7.0 112. 112. 112. 99.8 87.1 74.4 61.8 106.4 7.5 106. 106. 106. 93.8 81.1 68.4 55.8
57 112.8 6.9 112. 112. 112. 100. 87.5 74.8 62.2 105.8 7.5 105. 105. 105. 93.2 80.5 67.8 55.2
Temperature of Air on Condenser Coil 95°F Temperature of Air on Condenser Coil 105°F
2550
72 108.0 13.4 61.8 54.6 47.3 40.0 32.8 - - 99.4 11.5 59.2 52.0 44.7 37.4 30.2 - -
67 100.0 13.1 79.3 72.1 64.8 57.5 50.3 43.0 35.7 90.8 11.2 75.4 68.1 60.8 53.6 46.3 39.0 31.7
62 92.0 12.8 92.0 87.5 80.3 73.0 65.7 58.5 51.2 82.0 11.0 82.0 79.8 72.7 65.4 58.2 50.9 43.6
57 90.5 12.9 90.5 90.2 82.9 75.6 68.3 61.1 53.8 83.3 11.1 83.3 82.3 75.1 67.8 60.5 53.2 46.0
2975
72 111.3 10.9 68.2 59.7 51.1 42.5 33.9 - - 102.8 10.3 65.7 57.2 48.6 40.0 31.4 - -
67 103.1 10.7 87.1 78.5 69.9 61.4 52.8 44.2 35.6 93.9 10.0 83.3 74.7 66.1 57.5 48.9 40.3 31.7
62 94.8 10.4 94.8 92.6 86.6 78.0 69.4 60.9 52.3 84.8 9.8 84.8 83.7 79.0 70.4 61.8 53.2 44.6
57 93.3 10.5 93.3 93.1 89.5 80.9 72.3 63.7 55.1 86.2 9.9 86.2 85.7 81.5 72.9 64.3 55.7 47.1
3400
72 114.7 8.4 74.6 64.7 54.8 44.9 35.0 - - 106.2 9.1 72.3 62.3 52.4 42.5 32.6 - -
67 106.2 8.2 94.9 85.0 75.1 65.2 55.3 45.3 35.4 97.0 8.9 91.2 81.2 71.3 61.4 51.5 41.6 31.7
62 97.7 8.0 97.7 97.7 93.0 83.1 73.2 63.3 53.3 87.6 8.7 87.6 87.6 85.2 75.3 65.4 55.5 45.6
57 96.1 8.1 96.1 96.1 96.0 86.1 76.2 66.3 56.4 89.1 8.7 89.1 89.1 88.0 78.1 68.1 58.2 48.3
3825
72 116.3 8.4 80.2 68.9 57.6 46.3 35.0 - - 107.6 9.1 78.0 66.7 55.4 44.1 32.9 - -
67 107.7 8.3 101. 90.2 78.9 67.6 56.3 45.0 33.7 98.2 8.9 95.0 86.7 75.4 64.1 52.8 41.6 30.3
62 99.1 8.1 99.1 99.1 96.7 85.4 74.1 62.8 51.6 88.8 8.7 88.8 88.8 87.6 76.3 65.0 53.7 42.4
57 97.5 8.1 97.5 97.5 97.4 86.2 74.9 63.6 52.3 90.2 8.8 90.2 90.2 89.7 78.4 67.1 55.8 44.5
4250
72 117.9 8.4 85.7 73.0 60.3 47.7 35.0 - - 108.9 9.2 83.8 71.1 58.5 45.8 33.1 - -
67 109.2 8.3 108. 95.3 82.7 70.0 57.3 44.7 32.0 99.5 8.9 98.9 92.2 79.5 66.9 54.2 41.5 28.9
62 100.5 8.1 100. 100. 100. 87.8 75.1 62.4 49.8 89.9 8.8 89.9 89.9 89.9 77.2 64.6 51.9 39.2
57 98.9 8.1 98.9 98.9 98.9 86.2 73.5 60.8 48.2 91.3 8.8 91.3 91.3 91.3 78.7 66.0 53.3 40.7
Temperature of Air on Condenser Coil 115°F Temperature of Air on Condenser Coil 125°F
2550
72 90.8 9.6 56.6 49.4 42.1 34.8 27.5 - - 82.2 7.8 54.0 46.8 39.5 32.2 24.9 - -
67 81.6 9.4 71.4 64.1 56.8 49.6 42.3 35.0 27.8 72.3 7.5 67.4 60.1 52.9 45.6 38.3 31.0 23.8
62 72.1 9.2 72.1 72.1 65.1 57.9 50.6 43.3 36.0 62.1 7.3 62.1 62.1 57.6 50.3 43.0 35.7 28.5
57 76.2 9.3 76.2 74.5 67.2 59.9 52.7 45.4 38.1 69.0 7.5 69.0 66.7 59.4 52.1 44.8 37.6 30.3
2975
72 94.3 9.7 63.3 54.7 46.1 37.5 28.9 - - 85.8 9.1 60.8 52.2 43.6 35.0 26.4 - -
67 84.7 9.4 79.4 70.8 62.2 53.6 45.0 36.4 27.8 75.4 8.8 75.4 66.9 58.3 49.8 41.2 32.6 24.0
62 74.8 9.2 74.8 74.8 71.3 62.7 54.1 45.5 36.9 64.8 8.6 64.8 64.8 63.6 55.0 46.4 37.8 29.2
57 79.1 9.3 79.1 78.2 73.6 65.0 56.4 47.8 39.2 71.9 8.8 71.9 70.8 65.6 57.0 48.4 39.8 31.3
3400
72 97.7 9.8 69.9 60.0 50.0 40.1 30.2 - - 89.3 10.5 67.5 57.6 47.7 37.7 27.8 - -
67 87.8 9.5 87.4 77.5 67.6 57.7 47.8 37.8 27.9 78.6 10.1 78.6 73.7 63.8 53.9 44.0 34.1 24.2
62 77.6 9.3 77.6 77.6 77.4 67.5 57.6 47.7 37.8 67.5 9.9 67.5 67.5 67.5 59.7 49.8 39.9 30.0
57 82.0 9.4 82.0 82.0 79.9 70.0 60.1 50.2 40.3 74.9 10.1 74.9 74.9 71.9 62.0 52.0 42.1 32.2
3825
72 98.8 9.8 75.9 64.6 53.3 42.0 30.7 - - 90.1 10.6 73.7 62.5 51.2 39.9 28.6 - -
67 88.8 9.5 88.6 83.3 72.0 60.7 49.4 38.1 26.8 79.3 10.2 79.3 79.3 68.5 57.2 46.0 34.7 23.4
62 78.5 9.4 78.5 78.5 78.4 67.1 55.8 44.5 33.2 68.2 10.0 68.2 68.2 68.2 57.9 46.6 35.3 24.1
57 82.9 9.5 82.9 82.9 81.9 70.6 59.3 48.0 36.7 75.6 10.1 75.6 75.6 74.1 62.8 51.5 40.2 28.9
4250
72 100.0 9.9 81.9 69.2 56.6 43.9 31.2 - - 91.0 10.6 80.0 67.3 54.7 42.0 29.3 - -
67 89.8 9.6 89.8 89.1 76.4 63.7 51.0 38.4 25.7 80.0 10.3 80.0 80.0 73.2 60.6 47.9 35.2 22.6
62 79.3 9.4 79.3 79.3 79.3 66.7 54.0 41.3 28.7 68.8 10.1 68.8 68.8 68.8 56.1 43.5 30.8 18.1
57 83.8 9.5 83.8 83.8 83.8 71.2 58.5 45.8 33.2 76.3 10.2 76.3 76.3 76.3 63.7 51.0 38.3 25.6
1 These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air blower motor.
2 These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
