Unitary Products 19
TABLE 9: COOLING CAPACITY 43.9 KW UNIT - METRIC
Air On
Evap. Coil
Temperature of Air on Condenser Coil 29°C Temperature of Air on Condenser Coil 35°C
m
3
/s
WB
(°C)
Tot.
Cap.
1
(kW)
Tot.
Input
2
(kW)
Sensible Capacity (kW)
1
Return Dry Bulb (°C)
Tot.
Cap.
1
(kW)
Tot.
Input
2
(kW)
Sensible Capacity (kW)
1
Return Dry Bulb (°C)
30 28 27 25 23 22 20 30 28 27 25 23 22 20
1.77
22
44 11.8 26 23 20 17 14 - - 42 13.0 26 23 20 16 13 - -
19
41 11.5 34 31 27 24 21 18 15 39 12.6 33 30 26 23 20 17 14
17
36 11.2 36 34 31 28 25 21 18 34 12.4 34 33 30 27 24 20 17
14
35 11.3 35 34 31 28 25 21 18 33 12.5 33 33 29 26 23 20 17
2.06
22
46 11.8 29 26 22 18 15 - - 43 13.0 29 25 21 18 14 - -
19
42 11.5 37 34 30 26 23 19 15 40 12.5 36 33 29 25 21 18 14
17
37 11.2 37 36 34 30 26 23 19 35 12.4 35 35 33 29 25 22 18
14
36 11.3 36 36 34 30 26 23 19 34 12.4 34 34 32 28 25 21 17
2.36
22
47 11.8 33 28 24 20 15 - - 45 12.9 32 28 23 19 15 - -
19
44 11.5 41 37 33 28 24 20 15 42 12.5 40 36 31 27 23 19 14
17
39 11.3 39 39 37 32 28 24 20 37 12.3 37 37 35 31 27 23 18
14
37 11.3 37 37 37 32 28 24 20 35 12.4 35 35 35 31 26 22 18
2.65
22
48 11.9 39 34 29 24 19 - - 46 13.1 38 33 28 23 18 - -
19
45 11.6 44 41 39 34 30 25 20 43 12.6 42 40 38 33 28 23 18
17
39 11.3 39 39 39 34 29 24 19 38 12.5 38 38 37 32 27 22 18
14
38 11.4 38 38 38 33 28 23 18 36 12.5 36 36 36 31 26 21 16
2.95
22
49 11.9 45 39 34 28 23 - - 47 13.2 44 38 33 27 22 - -
19
46 11.6 46 46 46 41 35 30 24 44 12.8 44 44 44 38 33 27 22
17
40 11.4 40 40 40 35 30 24 19 39 12.6 39 39 39 33 28 22 17
14
39 11.4 39 39 39 33 28 22 17 37 12.7 37 37 37 31 26 21 15
Temperature of Air on Condenser Coil 41°C Temperature of Air on Condenser Coil 46°C
1.77
22
39 14.3 25 22 19 16 13 - - 37 15.6 24 21 18 15 12 - -
19
36 13.8 32 29 25 22 19 16 13 34 15.1 31 28 24 21 18 15 12
17
32 13.6 32 32 28 25 22 19 16 30 14.9 30 30 27 24 21 18 14
14
31 13.8 31 31 28 25 21 18 15 29 15.0 29 29 26 23 20 17 13
2.06
22
41 14.3 28 24 21 17 13 - - 38 15.6 27 23 20 16 12 - -
19
38 13.8 35 32 28 24 20 17 13 35 15.1 34 30 27 23 19 16 12
17
33 13.6 33 33 31 27 24 20 16 31 14.9 31 31 30 26 22 18 15
14
32 13.7 32 32 30 27 23 19 15 30 15.0 30 30 28 25 21 17 14
2.36
22
42 14.3 31 27 22 18 14 - - 40 15.6 30 26 21 17 13 - -
19
39 13.8 38 35 30 26 22 17 13 36 15.1 36 33 29 25 21 16 12
17
34 13.6 34 34 34 30 25 21 17 32 14.9 32 32 32 28 24 19 15
14
33 13.7 33 33 33 29 24 20 16 31 15.0 31 31 31 27 22 18 14
2.65
22
43 14.4 36 31 26 21 16 - - 40 15.7 33 29 24 19 14 - -
19
40 13.9 40 38 35 30 25 20 15 37 15.2 37 36 32 27 22 18 13
17
35 13.7 35 35 35 30 25 20 15 33 15.0 33 33 33 28 23 18 13
14
34 13.8 34 34 34 29 24 19 14 32 15.1 32 32 32 27 22 17 12
2.95
22
44 14.5 40 35 29 24 18 - - 41 15.8 37 32 26 21 15 - -
19
41 14.0 41 41 40 34 29 23 18 38 15.3 38 38 35 30 24 19 13
17
36 13.8 36 36 36 31 25 20 14 34 15.0 34 34 34 28 23 17 12
14
35 13.9 35 35 35 29 24 18 13 32 15.2 32 32 32 27 21 16 10
Temperature of Air on Condenser Coil 52°C
1.77
22
35 16.9 24 20 17 14 11 - -
19
32 16.4 30 27 23 20 17 14 11
17
28 16.1 28 28 26 22 19 16 13
14
27 16.3 27 27 24 21 18 15 12
2.06
22
36 16.9 26 23 19 15 11 - -
19
33 16.4 32 29 26 22 18 15 11
17
29 16.1 29 29 28 24 21 17 13
14
28 16.3 28 28 27 23 19 16 12
2.36
22
37 16.9 29 25 21 16 12 - -
19
34 16.4 34 32 28 24 19 15 11
17
30 16.1 30 30 30 26 22 18 13
14
29 16.3 29 29 29 25 20 16 12
2.65
22
37 17.0 31 27 22 17 12 - -
19
34 16.5 34 34 29 25 20 15 10
17
31 16.2 31 31 31 26 21 16 11
14
29 16.4 29 29 29 25 20 15 10
2.95
22
38 17.1 34 28 23 17 12 - -
19
35 16.5 35 35 31 26 20 15 9
17
31 16.3 31 31 31 26 20 15 9
14
30 16.5 30 30 30 24 19 14 8
1 These capacities are gross ratings. For net
capacity, deduct air blower motor, MBh = 3.415
x kW. Refer to the appropriate Blower
Performance Table for the kW of the supply air
blower motor.
2 These ratings include condenser fan motors
and the compressor motors but not the supply
air blower motor.
