Physical Data
XP078-150 Physical Data
Component
Models
XP078 XP090 XP102 XP120 XP150
Nominal Tonnage 6.5 7.5 8.5 10 12.5
AHRI COOLING PERFORMANCE
Gross Capacity @ AHRI A point (Mbh) 80000 92550 105600 122000 158300
AHRI net capacity (Mbh) 78000 90000 102000 117000 150000
EER 11.5 11.2 11.2 11.2 11.0
IEER 12.0 12.0 11.4 11.4 10.5
IPLV 12.4 12.4 12.4 12.4 11.9
Nominal CFM 2600 3000 3750 3750 4900
System power (KW) 6.78 8.18 9.27 10.45 13.64
Refrigerant type R-410A R-410A R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 14-2 13-0 13-12 12-14 17-6
System 2 12-10 13-2 13-13 12-12 17-8
AHRI HEATING PERFORMANCE
47°F capacity rating (Mbh) 75.0 88.0 90.5 102.0 135.0
System power (KW) / COP 6.2 / 3.35 7.7 / 3.35 7.9 / 3.35 8.6 / 3.30 13.2 / 3.0
17°F capacity rating (Mbh) 43.0 51.0 53.0 58.0 90.0
System power (KW) / COP 5.7 / 2.20 6.4 / 2.25 6.9 / 2.25 7.8 / 2.20 13.5 / 2.2
HSPF (Btu/Watts-hr) -----
DIMENSIONS (inches)
Length 89 89 89 89 119-7/16
Width 5959595959
Height 50-3/4 50-3/4 50-3/4 50-3/4 50-3/4
OPERATING WT. (lbs.) 1080 1090 1137 1135 1403
COMPRESSORS
Type Scroll Scroll Scroll Scroll Scroll
Quantity 2 2 2 2 2
Unit Capacity Steps (%) 50 / 100 50 / 100 50 / 100 50 / 100 50/100
CONDENSER COIL DATA
Face area (Sq. Ft.) 29.0 29.0 29.0 29.0 47.5
Rows 22222
Fins per inch 16 16 16 16 15
Tube diameter (in.) 3/8 3/8 3/8 3/8 3/8
Circuitry Type Split-face Split-face Split-face Split-face Split-face
Refrigerant control TXV 29.0 29.0 TXV TXV
EVAPORATOR COIL DATA
Face area (Sq. Ft.) 13.2 13.2 13.2 13.2 13.2
Rows 44444
Fins per inch 15 15 15 15 15
Tube diameter 3/8 3/8 3/8 3/8 3/8
Circuitry Type Split-face Split-face Split-face Split-face Split-face
Refrigerant control TXV TXV TXV TXV TXV
