Johnson Controls Unitary Products 11
Guide Specifications
GENERAL
Units shall be manufactured by York International Unitary
Products in an ISO 9001 certified facility. YORK® Predator
®
units are convertible single packages with a common footprint
cabinet and common roof curb for all 6.5 through 12.5 ton
models. All units have two compressors with independent R-
410A refrigeration circuits to provide 2 stages of cooling. The
units were designed for light commercial applications and can
be easily installed on a roof curb, slab, or frame. All Predator
®
units are self-contained and assembled on rigid full perimeter
base rails allowing for 3-way forklift access and overhead
rigging. Every unit is completely charged with R-410A, wired,
piped, and tested at the factory to provide a quick and easy
field installation. All units are convertible between side and
down airflow. Independent economizer designs are used on
side and down discharge applications, as well as all tonnage
sizes. Predator
®
units are available in the following
configurations: cooling only, cooling with electric heat, cooling
with gas heat, heat pump, and heat pump with electric heat.
Electric heaters are available as factory-installed options or
field-installed accessories.
DESCRIPTION
Units shall be factory assembled, single package, (Elec/Elec, Gas/
Elec), designed for outdoor installation. They shall have built in
field convertible duct connections for down discharge supply/return
or horizontal discharge supply/return and be available with factory
installed options or field installed accessories. The units shall be
factory wired, piped and charged with R-410A refrigerant and
factory tested prior to shipment. All unit wiring shall be both
numbered and color coded. The cooling performance shall be
rated in accordance with DOE and AHRI test procedures. Units
Field Installed Accessories - Fresh Air
MODEL VOLTAGE DESCRIPTION WHERE USED
1FA0413 All Manual Outside Air Damper 0-35%, Downflow All Cabinets
1FA0414 All Manual Outside Air Damper 0-100%, Downflow All Cabinets
1EH0408 All
Barometric Relief Kit for Power Exhaust, Horizontal
Application
All Cabinets
2EC0401 All Single Enthalpy Control All Cabinets
2EC0402 All Dual Enthalpy Control (Includes 2 Sensors) All Cabinets
2EE04707624 All
Economizer for Downflow, End Return Horizontal, or
ERV Applications. Includes FA Hood, Exhaust Hood w/
Baro Relief
All 50" Cabinets
2EE04707424 All
Economizer for Downflow, End Return Horizontal, or
ERV Applications. Includes FA Hood, Exhaust Hood w/
Baro Relief
All 42" Cabinets
2EE04706924 All Horizontal Economizer without Barometric Relief All Cabinets
2MD04703824 All Motorized Damper, Downflow without Barometric Relief All Cabinets
2MD04703924 All Motorized Damper, Horizontal without Barometric Relief All Cabinets
2PE04704706* 230 Power Exhaust 230V Downflow or Horizontal All Cabinets
2PE04704746* 460 Power Exhaust 460V Downflow or Horizontal All Cabinets
2PE04704758* 575 Power Exhaust 575V Downflow or Horizontal All Cabinets
Field Installed Accessories - Controls
MODEL VOLTAGE DESCRIPTION WHERE USED
2AP0401 All Air Proving Switch All Units
2AQ04700324 All CO2 Space Accessory All Units
2AQ04700424 All CO2 Unit Accessory All Units
2DF0402 All Dirty Air Switch All Units
2SH0401 All
Wall Mounted humidity sensor-For use with MagnaDry
Reheat or space humidity input to Smart Equipment™
board.
All Cabinets
2SD04700824 All Smoke Detector for Supply All Gen 5 units and greater with 2" & 4" Filters
2SD04700924 All Smoke Detector for Return All Gen 5 units and greater with 2" & 4" Filters
2SD04701024 All Smoke Detector for Supply and Return All Gen 5 units and greater with 2" & 4" Filters
S1-YK-
MAP1810-0P
All
MAP (Mobile Access Portal) Gateway- For use with
Smart Equipment™ Control.
All Units
S1-MP-PRTKIT-
0P
All
MAP (Multiple Access Portal) Gateway Kit- Replacement
MAP gateway protective case, lanyard and
communication cable. Use only to replace worn or
damaged components.
All Units
Field Installed Accessories - Electrical
MODEL VOLTAGE DESCRIPTION WHERE USED
2LA04704632 All Low Ambient Kit 3 - 10T Units
2LA04704633 All Low Ambient Kit 12.5T Units
Accessories (Continued)
To Next Page
