York TCGD18 THRU 60 User Manual

359315-YTG-B-0408
8 Johnson Controls Unitary Products
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL
VARIABLE SPEED
FURNACE MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH VARIABLE SPEED FURNACES
2
TCGD18S41S1(H)
PV8*A12 FC/MC/PC18A 14 600 17.5 13.4 14.00 12.50
PV9*A12 FC/MC/PC18A 14 625 17.5 13.3 14.00 12.50
P(C,V)9*B12 FC/MC/PC18B 17 620 17.5 13.3 14.00 12.50
PV8*A12 HC18 14 600 17.5 13.4 14.00 12.50
PV9*A12 HC18 14 625 17.5 13.3 14.00 12.50
TCGD24S41S1(H)
PV8*A12 FC/MC/PC32A 14 750 24.0 17.3 14.00 12.00
PV9*A12 FC/MC/PC32A 14 800 24.0 17.1 13.50 12.00
P(C,V)9*B12 FC/MC/PC35B 17 820 24.0 17.2 14.00 12.00
PV8*A12 FC/MC/PC36A 14 750 24.0 17.3 14.00 12.00
PV9*A12 FC/MC/PC36A 14 800 24.0 17.2 14.00 12.00
P(C,V)9*B12 FC/MC/PC36B 17 820 24.0 17.2 14.00 12.00
PV8*A12 FC/MC/PC37A 14 750 24.0 17.2 14.00 12.00
PV9*A12 FC/MC/PC37A 14 800 24.0 17.2 14.00 12.00
P(C,V)9*B12 FC/MC/PC43B 17 820 24.0 17.2 14.00 12.00
PV8*A12 HC30 14 750 24.0 17.3 14.00 12.00
PV9*A12 HC30 14 800 24.0 17.1 13.50 12.00
P(C,V)9*B12 HC36 17 820 24.0 17.2 14.00 12.00
TCGD30S41S1(H)
PV8*A12 FC/MC/PC32A 14 975 29.0 21.6 14.00 12.00
PV9*A12 FC/MC/PC32A 14 1000 29.0 21.4 13.50 12.00
PV8*B16 FC/MC/PC35B 17 1050 29.0 21.6 14.00 12.00
P(C,V)9*B12 FC/MC/PC35B 17 975 29.0 21.6 14.00 12.00
PV8*C16 FC/MC/PC35C 21 1000 30.0 21.8 14.00 12.00
PV8*C20 FC/MC/PC35C 21 1120 29.0 21.4 13.50 11.00
P(C,V)9*C16 FC/MC/PC35C 21 1010 29.0 21.6 14.00 12.00
P(C,V)9*C20 FC/MC/PC35C 21 1045 29.0 21.6 14.00 12.00
PV8*A12 FC/MC/PC37A 14 975 29.0 21.6 14.00 12.00
PV9*A12 FC/MC/PC37A 14 1000 30.0 21.4 13.50 12.00
PV8*B16 FC/MC/PC43B 17 1050 29.0 21.6 14.00 12.00
P(C,V)9*B12 FC/MC/PC43B 17 975 29.0 21.6 14.00 12.00
PV8*C16 FC/MC/PC43C 21 1000 30.0 21.8 14.00 12.00
PV8*C20 FC/MC/PC43C 21 1120 29.0 21.4 13.50 11.00
P(C,V)9*C16 FC/MC/PC43C 21 1010 29.0 21.6 14.00 12.00
P(C,V)9*C20 FC/MC/PC43C 21 1045 29.0 21.6 14.00 12.00
PV8*B16 HC36 17 1050 29.0 21.6 14.00 12.00
P(C,V)9*B12 HC36 17 975 29.0 21.6 14.00 12.00
PV8*C16 HC42 21 1000 30.0 21.8 14.00 12.00
PV8*C20 HC42 21 1120 29.0 21.4 13.50 11.00
P(C,V)9*C16 HC42 21 1010 29.0 21.6 14.00 12.00
P(C,V)9*C20 HC42 21 1045 29.0 21.6 14.00 12.00
TCGD36S41S1(H)
PV8*A12 FC/MC/PC37A 14 1185 35.0 25.0 13.00 12.00
PV9*A12 FC/MC/PC37A 14 1200 35.0 25.0 13.00 11.00
PV8*B16 FC/MC/PC43B 17 1200 35.0 25.2 13.50 12.00
P(C,V)9*B12 FC/MC/PC43B 17 1185 35.0 25.2 13.50 12.00
PV8*C16 FC/MC/PC43C 21 1200 35.0 25.4 14.00 12.00
PV8*C20 FC/MC/PC43C 21 1200 35.0 25.2 13.50 12.00
P(C,V)9*C16 FC/MC/PC43C 21 1175 35.0 25.2 13.50 12.00
P(C,V)9*C20 FC/MC/PC43C 21 1195 35.0 25.2 13.50 12.00
PV8*C16 FC/MC/PC48C 21 1200 36.0 25.4 14.00 12.00
For Notes See Page 9.
