York Y34 User Manual

246653-YTG-E-0108
Johnson Controls Unitary Products 63
TABLE 48: ELECTRICAL DATA 25 TON WITH ELECTRIC HEAT R22
VOLTAGE
COMPRESSORS
(EACH)
OD F
AN MOTORS
(EACH)
S
UPPLY BLOWER ELECTRIC HEAT
MCA
1
(AMPS)
M
AX
FUSE
2
/
B
REAKER
3
SIZE
QTY. RLA LRA MCC QTY FLA HP FLA OPTION KW
APPLIED
KW
STAGES
208-3-60 2 42.3 245 66.0 4 3.8
7.5 24.2 E4 40 30 1 137 175
10 30.8 E4 40 30 1 144 175
15 46.2 E4 40 30 1 162 200
20 59.4 E4 40 30 1 178 225
7.5 24.2 E8 80 60 2 197 225
10 30.8 E8 80 60 2 205 225
15 46.2 E8 80 60 2 225 250
20 59.4 E8 80 60 2 241 300
230-3-60 2 42.3 245 66.0 4 3.8
7.5 22.0 E4 40 36.8 1 148 175
10 28.0 E4 40 36.8 1 155 175
15 42.0 E4 40 36.8 1 173 175
20 54.0 E4 40 36.8 1 188 200
7.5 22.0 E8 80 73.6 2 220 250
10 28.0 E8 80 73.6 2 227 250
15 42.0 E8 80 73.6 2 245 250
20 54.0 E8 80 73.6 2 260 300
460-3-60 2 17.6 125 27.5 4 1.9
7.5 11.0 E4 40 36.8 1 74 80
10 14.0 E4 40 36.8 1 78 80
15 21.0 E4 40 36.8 1 86 90
20 27.0 E4 40 36.8 1 94 110
7.5 11.0 E8 80 73.6 2 110 125
10 14.0 E8 80 73.6 2 114 125
15 21.0 E8 80 73.6 2 122 125
20 27.0 E8 80 73.6 2 130 150
7.5 11.0 E1 108 99.4 2 144 175
10 14.0 E1 108 99.4 2 147 175
15 21.0 E1 108 99.4 2 156 175
20 27.0 E1 108 99.4 2 164 175
575-3-60 2 14.2 100 22.2 4 1.5
7.5 9.0 E4 40 36.8 1 59 60
10 11.0 E4 40 36.8 1 62 70
15 17.0 E4 40 36.8 1 69 70
20 22.0 E4 40 36.8 1 76 80
7.5 9.0 E8 80 73.6 2 88 100
10 11.0 E8 80 73.6 2 91 100
15 17.0 E8 80 73.6 2 98 110
20 22.0 E8 80 73.6 2 104 125
7.5 9.0 E1 108 99.4 2 115 125
10 11.0 E1 108 99.4 2 118 150
15 17.0 E1 108 99.4 2 125 150
20 22.0 E1 108 99.4 2 131 150
1.
Minimum Circuit Ampacity.
2.
Dual Element, Time Delay Type.
3.
HACR type per NEC
