York YCAL0134 User Manual

JOHNSON CONTROLS
22
Ratings - R-407C (English Units)
NOTES:
1. kW = Compressor Input Power
2. EER = Chiller EER (includes power from compressors, fans, and the control panels 0.8 kW)
3. LCWT = Leaving Chilled Water Temperature
4. Ratings are based upon 2.4 GPM cooler water per ton and 0.0001 fouling factor
5. Rated in accordance with ARI Standard 550/590-98
6. The shaded points are certied in accordance with ARI Standard 550/590-98
YCAL0014EB
IPLV=12.6
YCAL0020EB
IPLV=12.9
YCAL0024EB
IPLV=13.2
YCAL0030EB
IPLV=13.6
AIR TEMPERATURE ON CONDENSER (°F)
LCWT
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0
18.2 16.4 11.4 17.7 17.5 10.5 17.2 18.6 9.6 16.6 19.7 8.9 16.1 21.0 8.1 15.6 22.2 7.5
42.0
18.9 16.5 11.7 18.4 17.6 10.8 17.8 18.7 10.0 17.3 19.9 9.2 16.7 21.1 8.4 16.2 22.4 7.7
44.0
19.6 16.6 12.1 19.1 17.7 11.2 18.5 18.8 10.3 17.9 20.0 9.5 17.4 21.2 8.7 16.8 22.5 8.0
45.0
20.0 16.7 12.3 19.4 17.8 11.3 18.9 18.9 10.5 18.3 20.0 9.6 17.7 21.3 8.8 17.1 22.6 8.1
46.0
20.4 16.8 12.5 19.8 17.8 11.5 19.2 18.9 10.6 18.6 20.1 9.8 18.0 21.3 9.0 17.5 22.6 8.2
48.0
21.1 16.9 12.9 20.5 17.9 11.9 19.9 19.0 10.9 19.3 20.2 10.1 18.7 21.5 9.3 18.1 22.8 8.5
50.0
21.9 17.0 13.3 21.3 18.0 12.2 20.7 19.2 11.3 20.0 20.4 10.4 19.4 21.6 9.5 18.8 22.9 8.8
AIR TEMPERATURE ON CONDENSER (°F)
LCWT
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0
22.7 20.5 11.7 22.1 21.7 10.8 21.4 23.0 10.0 20.9 24.1 9.3 20.2 25.6 8.6 19.5 27.1 7.9
42.0
23.6 20.6 12.1 22.9 21.8 11.2 22.3 23.1 10.3 21.6 24.5 9.5 20.9 26.0 8.7 20.2 27.5 8.0
44.0
24.5 20.8 12.5 23.8 22.0 11.5 23.1 23.3 10.7 22.4 24.7 9.8 21.7 26.1 9.0 21.0 27.7 8.3
45.0
24.9 20.9 12.6 24.2 22.1 11.7 23.6 23.3 10.8 22.9 24.7 10.0 22.1 26.2 9.2 21.4 27.8 8.4
46.0
25.4 21.0 12.8 24.7 22.2 11.9 24.0 23.5 11.0 23.3 24.8 10.1 22.6 26.3 9.3 21.8 27.9 8.5
48.0
26.3 21.1 13.2 25.6 22.3 12.2 24.9 23.6 11.3 24.2 25.0 10.4 23.4 26.5 9.6 22.6 28.0 8.8
50.0
27.3 21.3 13.6 26.6 22.5 12.6 25.8 23.8 11.6 25.1 25.2 10.7 24.3 26.7 9.9 23.5 28.3 9.1
AIR TEMPERATURE ON CONDENSER (°F)
LCWT
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0
27.9 24.7 12.2 27.2 26.2 11.2 26.4 27.8 10.4 25.5 29.9 9.4 24.9 31.3 8.8 24.1 33.2 8.0
42.0
28.9 25.1 12.4 28.1 26.6 11.5 27.3 28.3 10.5 26.5 30.0 9.7 25.7 31.9 8.9 24.9 33.8 8.2
44.0
30.0 25.2 12.8 29.2 26.8 11.8 28.4 28.4 10.9 27.6 30.2 10.0 26.7 32.0 9.2 25.9 33.9 8.5
45.0
30.5 25.3 13.0 29.7 26.8 12.0 28.9 28.5 11.1 28.1 30.3 10.2 27.2 32.1 9.4 26.4 34.0 8.6
46.0
31.1 25.4 13.2 30.3 26.9 12.2 29.4 28.6 11.3 28.6 30.3 10.4 27.8 32.2 9.5 26.9 34.1 8.7
48.0
32.2 25.5 13.6 31.4 27.1 12.6 30.5 28.8 11.6 29.7 30.5 10.7 28.8 32.4 9.8 27.9 34.3 9.0
50.0
33.4 25.7 14.1 32.5 27.3 13.0 31.6 29.0 12.0 30.7 30.7 11.0 29.8 32.6 10.1 28.9 34.5 9.3
AIR TEMPERATURE ON CONDENSER (°F)
LCWT
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
40.0
13.4 11.2 11.4 13.0 11.9 10.6 12.6 12.7 9.8 12.3 13.5 9.0 11.7 14.7 8.0 11.3 15.6 7.3
42.0
13.9 11.3 11.8 13.5 12.0 11.0 13.1 12.7 10.2 12.7 13.5 9.4 12.2 14.7 8.3 11.7 15.6 7.6
44.0
14.4 11.3 12.3 14.1 12.0 11.4 13.7 12.8 10.5 13.2 13.6 9.7 12.7 14.8 8.6 12.2 15.7 7.9
45.0
14.7 11.4 12.5 14.3 12.1 11.6 13.9 12.8 10.7 13.5 13.6 9.9 12.9 14.8 8.8 12.5 15.7 8.1
46.0
15.0 11.4 12.7 14.6 12.1 11.8 14.2 12.8 10.9 13.8 13.6 10.0 13.2 14.8 9.0 12.7 15.7 8.3
48.0
15.6 11.5 13.1 15.2 12.2 12.2 14.7 12.9 11.2 14.3 13.7 10.4 13.7 14.8 9.3 13.2 15.7 8.6
50.0
16.2 11.5 13.5 15.7 12.2 12.6 15.3 13.0 11.6 14.8 13.8 10.7 14.2 14.8 9.7 13.8 15.8 8.9
