York YCAL0134 User Manual

JOHNSON CONTROLS
77
FORM 150.62-EG1 (507)
COPPER FIN COILS
English Units
SI Units
Copper Fin Coil Weight Distribution (lbs)
YCAL A B C D E F G H Total
0014 718 581 809 654 --- --- --- --- 2,762
0020 722 584 814 658 --- --- --- --- 2,778
0024 854 704 941 776 --- --- --- --- 3,275
0030 830 776 912 853 --- --- --- --- 3,371
0034 954 885 974 904 --- --- --- --- 3,717
0040 1,354 1,292 1,358 1,296 --- --- --- --- 5,300
0042 1,375 1,315 1,366 1,307 --- --- --- --- 5,363
0044 1,384 1,327 1,389 1,332 --- --- --- --- 5,433
0050 1,410 1,355 1,403 1,348 --- --- --- --- 5,517
0060 1,426 1,372 1,430 1,377 --- --- --- --- 5,605
0064 1,766 1,577 1,747 1,561 --- --- --- --- 6,651
0070 1,799 1,612 1,803 1,616 --- --- --- --- 6,829
0074 1,852 1,662 1,838 1,649 --- --- --- --- 7,001
00
80 1,903 1,704 1,907 1,708 --- --- --- --- 7,222
00
90 1,427 1,310 1,193 1,409 1,293 1,177 --- --- 7,809
0094 1,414 1,326 1,237 1,391 1,304 1,216 --- --- 7,888
0104 1,460 1,251 1,041 832 1,364 1,169 973 777 8,867
0114 1,688 1,483 1,279 1,074 1,597 1,404 1,210 1,017 10,751
0124 1,799 1,560 1,320 1,081 1,649 1,430 1,210 990 11,039
01
34 1,859 1,626 1,393 1,160 1,659 1,451 1,243 1,035 11,427
Copper Fin Coil Weight Distribution (kg)
YCAL A B C D E F G H Total
0014 326 263 367 297 --- --- --- --- 1,253
0020 327 265 369 299 --- --- --- --- 1,260
0024 387 319 427 352 --- --- --- --- 1,486
0030 377 352 414 387 --- --- --- --- 1,529
00
34 433 402 442 410 --- --- --- --- 1,686
0040 614 586 616 588 --- --- --- --- 2,404
0042 624 597 620 593 --- --- --- --- 2,432
0044 628 602 630 604 --- --- --- --- 2,464
0050 640 615 637 612 --- --- --- --- 2,502
0060 647 622 649 624 --- --- --- --- 2,542
0064 801 715 793 708 --- --- --- --- 3,017
0070 816 731 818 733 --- --- --- --- 3,098
0074 840 754 833 748 --- --- --- --- 3,176
0080 863 773 865 775 --- --- --- --- 3,276
0090 647 594 541 639 586 534 --- --- 3,542
0094 641 601 561 631 591 552 --- --- 3,578
0104 662 567 472 377 619 530 441 352 4,022
0114 765 673 580 487 724 637 549 461 4,877
0124 816 707 599 490 748 648 549 449 5,007
01
34 843 738 632 526 752 658 564 470 5,183
