York YCAL0134 User Manual

JOHNSON CONTROLS
85
FORM 150.62-EG1 (507)
YCAL0014 - YCAL0034
OVER CURRENT PROTECTION,
UNIT VOLTAGE UNIT VOLTAGE CONTROL POWER
MCA
SEE NOTE B NF DISC Sw
NOTE A MIN MAX
MODELS w/o
CONTROL TRANS 1
15‑1‑60/50 15A 10A 15A 30 A / 240V
‑17 200‑1‑60 15A 10A 15A 30 A / 240V
‑28 230‑1‑60 15A 10A 15A 30 A / 240V
MODELS w/
‑
40 380‑1‑60 15A 10A 15A 30 A / 480V
CONTROL TRANS
‑
46 460‑1‑60 15A 10A 15A 30 A / 480V
‑58 575‑1‑60 15A 10A 15A 30 A / 600V
A. Minimum #14 AWG, 75°C, Copper Recommended
B. Minimum and Maximum Over Current Protection, Dual Element Fuse or Circuit Breaker
SINGLE POINT POWER SUPPLY CONNECTIONS (See Fig. 1)
(One Field Provided Power Supply to the chiller. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Disconnect Switch (optional)
or Circuit Breaker (optional).)
MODEL
YCAL
VOLT HZ
SINGLE POINT FIELD SUPPLIED WIRING SYSTEM #1 COMPRESSOR & FAN
MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
COMPR. #1 COMPR. #2 COMPR. #3 FANS
TERMINAL
BLOCK
(std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)
MIN
3
MAX
4
MIN MAX RLA LRA RLA LRA RLA LRA QTY
FLA
(EA)
0014
200 60 81 100 90 100 90 100 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 28.3 189 28.3 189 — — 2 7.6
230 60 75 100 90 100 90 100 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 26.2 189 26.2 189 — — 2 7.4
380 60 44 60 50 50 50 50 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 15.1 112 15.1 112 — — 2 4.5
460 60 37 60 40 45 40 45 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 12.5 99 12.5 99 — — 2 4.0
575 60 29 60 35 35 35 35 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 10.0 74 10.0 74 — — 2 2.9
0020
200 60 101 150 110 125 110 125 #
10 ‑ # 1 # 14 ‑ 1/0 # 2 ‑ 4/0 37.4 278 37.4 278 — — 2 7.6
230 60 94 100 110 125 110 125 #
10 ‑ # 1 # 14 ‑ 1/0 # 2 ‑ 4/0 34.6 278 34.6 278 — — 2 7.4
380 60 54 60 60 70 60 70 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 19.9 151 19.9 151 — — 2 4.5
460 60 46 60 50 60 50 60 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 16.5 127 16.5 127 — — 2 4.0
575 60 36 60 40 45 40 45 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 13.2 100 13.2 100 — — 2 2.9
0024
200 60 128 150 150 175 150 175 #
10 ‑ 3/0 # 2 ‑ 4/0 # 2 ‑ 4/0 49.4 350 49.4 350 — — 2 7.6
230 60 119 150 150 150 150 150 #
10 ‑ 3/0 # 2 ‑ 4/0 # 2 ‑ 4/0 45.8 350 45.8 350 — — 2 7.4
380 60 69 100 80 90 80 90 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 26.4 195 26.4 195 — — 2 4.5
460 60 58 60 70 70 70 70 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 21.8 158 21.8 158 — — 2 4.0
575 60 46 60 50 60 50 60 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 17.4 125 17.4 125 — — 2 2.9
0030
200 60 138 150 175 175 175 175 #
10 ‑ 3/0 # 2 ‑ 4/0 # 3 ‑ 300 53.8 425 53.8 425 — — 2 7.6
230 60 128 150 150 175 150 175 #
10 ‑ 3/0 # 2 ‑ 4/0 # 3 ‑ 300 49.8 425 49.8 425 — — 2 7.4
380 60 74 100 90 100 90 100 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 28.7 239 28.7 239 — —‑ 2 4.5
460 60 62 100 70 80 70 80 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 23.7 187 23.7 187 — — 2 4.0
575 60 49 60 60 60 60 60 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 2 19.0 148 19.0 148 — — 2 2.9
0034
200 60 178 200 200 225 200 225 #
10 ‑ 300 # 3 ‑ 300 # 3 ‑ 300 49.4 350 49.4 350 49.4 350 2 7.6
230 60 165 200 200 200 200 200 #
10 ‑ 300 # 3 ‑ 300 # 3 ‑ 300 45.8 350 45.8 350 45.8 350 2 7.4
380 60 96 150 110 110 110 110 #
10 ‑ # 1 # 14 ‑ 1/0 # 2 ‑ 4/0 26.4 195 26.4 195 26.4 195 2 4.5
460 60 79 100 90 100 90 100 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 21.8 158 21.8 158 21.8 158 2 4.0
575 60 63 100 70 70 70 70 #
10 ‑ # 1 # 14 ‑ 1/0 # 14 ‑ 1/0 17.4 125 17.4 125 17.4 125 2 2.9
VOLTAGE RANGE
VOLTAGE CODE UNIT POWER MIN. MAX.
-17 200-3-60 180 220
-28 230-3-60 207 253
-40 380/415-3-60 342 440
-46 460-3-60 414 506
-58 575-3-60 517 633
