York YCE24B21H User Manual

5005746-YTG-A-0815
Johnson Controls Unitary Products 57
COIL MULTIPLIERS- 3 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU36B 1.00 1.00 1.00
– CF/CM/CU36C 1.01 1.01 1.01
– CF/CM/CU36D 1.01 1.01 1.01
– CF/CM/CU42C 1.01 1.02 1.01
– CF/CM/CU42D 1.01 1.02 1.01
– CF/CM/CU48C 1.02 1.01 1.02
– CF/CM/CU48D 1.02 1.01 1.02
– CF42B 1.01 1.02 1.01
AE36BX21 – 0.99 0.93 0.95
AE36CX21 – 1.03 1.04 0.95
AE42CX21 – 1.03 1.04 0.97
AE48CX21 – 1.04 1.06 0.96
AE48DX21 – 1.04 1.05 0.96
AP36BX21 – 0.98 0.92 0.98
AP36CX21 – 1.01 1.02 1.01
AP42CX21 – 1.01 1.02 1.03
AP48CX21 – 1.02 1.01 1.02
AP48DX21 – 1.03 1.07 1.03
AVC36BX21 – 1.00 0.95 0.96
AVC36CX21 – 1.02 1.02 0.94
AVC42CX21 – 1.03 1.02 0.95
AVC48CX21 – 1.02 0.98 0.94
AVC48DX21 – 1.04 1.10 0.96
ME12BN21 CF/CM36B 1.00 0.95 0.96
ME12BN21 CF42B 1.00 0.93 0.96
ME14DN21 CF/CM36D 1.04 1.06 0.98
ME14DN21 CF/CM42D 1.04 1.06 0.96
ME14DN21 CF/CM48D 1.04 1.04 0.96
ME16CN21 CF/CM36C 1.03 1.05 0.95
ME16CN21 CF/CM42C 1.03 1.06 0.95
ME16CN21 CF/CM48C 1.04 1.05 0.96
ME20DN21 CF/CM36D 1.03 1.08 1.01
ME20DN21 CF/CM42D 1.03 1.09 1.01
ME20DN21 CF/CM48D 1.04 1.08 1.00
MVC08BN21 CF42B 0.99 0.93 0.95
MVC12BN21 CF/CM36B 0.99 0.94 0.95
MVC12BN21 CF42B 1.00 0.93 0.96
MVC14DN21 CF/CM36D 0.99 0.93 0.92
MVC14DN21 CF/CM42D 1.04 1.08 0.96
MVC14DN21 CF/CM48D 1.03 1.02 0.95
MVC16CN21 CF/CM36C 1.01 0.98 0.93
MVC16CN21 CF/CM42C 1.04 1.07 0.96
MVC16CN21 CF/CM48C 1.04 1.04 0.96
MVC20DN21 CF/CM36D 1.02 1.00 0.94
MVC20DN21 CF/CM42D 1.03 1.04 0.97
MVC20DN21 CF/CM48D 1.04 1.04 0.96
FURNACE MULTIPLIERS- 3 TON
Furnaces Coil T.C. S.C. KW
TM8V060A12MP11 CF/CM36A 0.98 0.91 0.98
TM8V080B12MP11 CF/CM/CU36B 0.99 0.93 0.97
TM8V080B12MP11 CF42B 0.99 0.93 0.95
TM8V080C16MP11 CF/CM/CU36C 1.01 0.98 0.95
TM8V080C16MP11 CF/CM/CU42C 1.03 1.08 0.99
TM8V080C16MP11 CF/CM/CU48C 1.01 0.97 0.95
TM8V080C16MP11 CF/CM/CU48D 1.01 0.97 0.95
TM8V100C16MP11 CF/CM/CU36C 1.01 0.98 0.95
TM8V100C16MP11 CF/CM/CU42C 1.03 1.08 0.99
TM8V100C16MP11 CF/CM/CU48C 1.01 0.97 0.95
TM8V100C16MP11 CF/CM/CU48D 1.01 0.97 0.95
TM8V100C20MP11 CF/CM/CU36C 1.01 0.98 0.96
TM8V100C20MP11 CF/CM/CU42C 1.02 0.99 0.96
TM8V100C20MP11 CF/CM/CU48C 1.03 1.06 0.97
TM8V100C20MP11 CF/CM/CU48D 1.03 1.02 0.94
TM8V120C20MP11 CF/CM/CU36C 1.01 0.98 0.96
TM8V120C20MP11 CF/CM/CU42C 1.02 0.99 0.96
TM8V120C20MP11 CF/CM/CU48C 1.03 1.06 0.97
TM8V120C20MP11 CF/CM/CU48D 1.03 1.02 0.94
TM8X060A12MP11 CF/CM36A 0.98 0.92 0.94
TM8X080B12MP11 CF/CM/CU36B 0.99 0.92 0.95
TM8X080B12MP11 CF42B 1.00 0.93 0.96
TM8X080C16MP11 CF/CM/CU36C 1.01 0.96 0.95
TM8X080C16MP11 CF/CM/CU36D 1.01 0.98 0.95
TM8X080C16MP11 CF/CM/CU42C 1.03 1.05 0.97
TM8X080C16MP11 CF/CM/CU42D 1.02 0.98 0.94
TM8X080C16MP11 CF/CM/CU48C 1.04 1.05 0.98
TM8X080C16MP11 CF/CM/CU48D 1.02 0.98 0.94
TM8X100C16MP11 CF/CM/CU36C 1.01 0.96 0.95
TM8X100C16MP11 CF/CM/CU36D 1.01 0.98 0.95
TM8X100C16MP11 CF/CM/CU42C 1.03 1.05 0.97
TM8X100C16MP11 CF/CM/CU42D 1.02 0.98 0.94
TM8X100C16MP11 CF/CM/CU48C 1.04 1.05 0.98
TM8X100C16MP11 CF/CM/CU48D 1.02 0.98 0.94
TM8X100C20MP11 CF/CM/CU36C 1.03 1.07 0.97
TM8X100C20MP11 CF/CM/CU36D 1.04 1.07 0.98
TM8X100C20MP11 CF/CM/CU42C 1.02 0.98 0.96
TM8X100C20MP11 CF/CM/CU42D 1.02 1.00 0.94
TM8X100C20MP11 CF/CM/CU48C 1.04 1.08 0.96
TM8X100C20MP11 CF/CM/CU48D 1.03 1.03 0.97
TM8X120C20MP11 CF/CM/CU36C 1.03 1.07 0.97
TM8X120C20MP11 CF/CM/CU36D 1.04 1.07 0.98
TM8X120C20MP11 CF/CM/CU42C 1.02 0.98 0.96
TM8X120C20MP11 CF/CM/CU42D 1.02 1.00 0.94
TM8X120C20MP11 CF/CM/CU48C 1.04 1.08 0.96
TM8X120C20MP11 CF/CM/CU48D 1.03 1.03 0.97
TM8Y060A12MP11 CF/CM36A 0.98 0.92 0.94
TM8Y080B12MP11 CF/CM/CU36B 0.99 0.92 0.95
TM8Y080B12MP11 CF42B 1.00 0.93 0.96
TM8Y080C16MP11 CF/CM/CU36C 1.01 0.96 0.95
TM8Y080C16MP11 CF/CM/CU36D 1.01 0.98 0.95
TM8Y080C16MP11 CF/CM/CU42C 1.03 1.05 0.97
TM8Y080C16MP11 CF/CM/CU42D 1.02 0.98 0.94
TM8Y080C16MP11 CF/CM/CU48C 1.04 1.05 0.98
TM8Y080C16MP11 CF/CM/CU48D 1.02 0.98 0.94
FURNACE MULTIPLIERS- 3 TON (Continued)
Furnaces Coil T.C. S.C. KW

York YCE24B21H Specifications

General

Brand	York
Model	YCE24B21H
Category	Air Conditioner
Language	English
