York YCE24B21H User Manual

5005746-YTG-A-0815
66 Johnson Controls Unitary Products
COIL MULTIPLIERS- 4 TON
Air Handler Coil T.C. S.C. KW
– CF/CM/CU48C 1.00 0.99 1.00
– CF/CM/CU48D 1.00 0.99 1.00
– CF/CM/CU60C 1.01 1.05 0.97
– CF/CM/CU60D 1.01 1.05 0.99
– CF/CM64D 1.01 1.05 0.97
AE48CX21 – 0.99 0.98 0.91
AE48DX21 – 0.99 0.99 0.91
AE60CX21 – 1.00 1.01 0.92
AE60DX21 – 1.01 1.01 0.91
AP48CX21 – 1.01 0.98 1.01
AP48DX21 – 1.00 0.99 1.00
AP60CX21 – 1.01 1.07 0.99
AP60DX21 – 1.01 1.05 1.01
AVC48CX21 – 1.01 0.99 0.95
AVC48DX21 – 1.01 1.01 0.93
AVC60CX21 – 1.01 1.01 0.93
AVC60DX21 – 1.01 1.02 0.93
ME14DN21 CF/CM60D 1.01 1.01 0.93
ME14DN21 CF/CM64D 1.01 0.99 0.91
ME16CN21 CF/CM48C 1.01 1.04 0.93
ME16CN21 CF/CM60C 1.01 1.02 0.93
ME20DN21 CF/CM48D 1.01 1.04 0.93
ME20DN21 CF/CM60D 1.01 1.01 0.93
ME20DN21 CF/CM64D 1.01 1.02 0.91
MVC14DN21 CF/CM48D 1.01 0.98 0.93
MVC14DN21 CF/CM60D 1.01 0.98 0.93
MVC14DN21 CF/CM64D 1.01 0.98 0.91
MVC16CN21 CF/CM48C 1.01 1.01 0.93
MVC16CN21 CF/CM60C 1.01 1.08 0.91
MVC20DN21 CF/CM48D 1.01 1.02 0.93
MVC20DN21 CF/CM60D 1.01 1.04 0.93
MVC20DN21 CF/CM64D 1.01 0.99 0.91
FURNACE MULTIPLIERS- 4 TON
Furnaces Coil
T.C. S.C. KW
TM8V080C16MP11 CF/CM/CU48C 0.99 0.96 0.93
TM8V080C16MP11 CF/CM/CU48D 1.01 0.98 0.95
TM8V080C16MP11 CF/CM/CU60C 0.99 0.96 0.91
TM8V080C16MP11 CF/CM/CU60D 0.99 0.96 0.91
TM8V080C16MP11 CF/CM64D 1.01 1.01 0.93
TM8V100C16MP11 CF/CM/CU48C 0.99 0.96 0.93
TM8V100C16MP11 CF/CM/CU48D 1.01 0.98 0.95
TM8V100C16MP11 CF/CM/CU60C 0.99 0.96 0.91
TM8V100C16MP11 CF/CM/CU60D 0.99 0.96 0.91
TM8V100C16MP11 CF/CM64D 1.01 1.01 0.93
TM8V100C20MP11 CF/CM/CU48C 0.99 0.96 0.93
TM8V100C20MP11 CF/CM/CU48D 1.01 1.04 0.93
TM8V100C20MP11 CF/CM/CU60C 1.00 0.99 0.92
TM8V100C20MP11 CF/CM/CU60D 0.99 0.96 0.93
TM8V100C20MP11 CF/CM64D 1.00 1.01 0.94
TM8V120C20MP11 CF/CM/CU48C 0.99 0.96 0.93
TM8V120C20MP11 CF/CM/CU48D 1.01 1.04 0.93
TM8V120C20MP11 CF/CM/CU60C 1.00 0.99 0.92
TM8V120C20MP11 CF/CM/CU60D 0.99 0.96 0.93
TM8V120C20MP11 CF/CM64D 1.00 1.01 0.94
TM8X080C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8X080C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8X080C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8X080C16MP11 CF/CM/CU60D 1.00 0.99 0.94
TM8X080C16MP11 CF/CM64D 1.00 0.99 0.92
TM8X100C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8X100C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8X100C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8X100C16MP11 CF/CM/CU60D 1.00 0.99 0.94
TM8X100C16MP11 CF/CM64D 1.00 0.99 0.92
TM8X100C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8X100C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8X100C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8X100C20MP11 CF/CM/CU60D 1.01 1.02 0.93
TM8X100C20MP11 CF/CM64D 1.00 1.01 0.92
TM8X120C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8X120C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8X120C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8X120C20MP11 CF/CM/CU60D 1.01 1.02 0.93
TM8X120C20MP11 CF/CM64D 1.00 1.01 0.92
TM8Y080C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8Y080C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8Y080C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8Y080C16MP11 CF/CM/CU60D 1.00 0.99 0.94
TM8Y080C16MP11 CF/CM64D 1.00 0.99 0.92
TM8Y100C16MP11 CF/CM/CU48C 1.00 1.01 0.96
TM8Y100C16MP11 CF/CM/CU48D 1.00 0.99 0.94
TM8Y100C16MP11 CF/CM/CU60C 1.00 0.99 0.94
TM8Y100C16MP11 CF/CM/CU60D 1.00 0.99 0.94
TM8Y100C16MP11 CF/CM64D 1.00 0.99 0.92
TM8Y100C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8Y100C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8Y100C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8Y100C20MP11 CF/CM/CU60D 1.01 1.02 0.93
TM8Y100C20MP11 CF/CM64D 1.00 1.01 0.92
TM8Y120C20MP11 CF/CM/CU48C 0.99 0.98 0.93
TM8Y120C20MP11 CF/CM/CU48D 0.99 0.96 0.91
TM8Y120C20MP11 CF/CM/CU60C 1.00 1.02 0.92
TM8Y120C20MP11 CF/CM/CU60D 1.01 1.02 0.93
TM8Y120C20MP11 CF/CM64D 1.00 1.01 0.92
TM9E080C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9E080C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9E080C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9E080C16MP11 CF/CM/CU60D 0.99 0.96 0.93
TM9E080C16MP11 CF/CM64D 0.99 0.95 0.93
TM9E100C16MP11 CF/CM/CU48C 0.98 0.95 0.94
TM9E100C16MP11 CF/CM/CU48D 0.98 0.95 0.94
TM9E100C16MP11 CF/CM/CU60C 1.00 0.98 0.94
TM9E100C16MP11 CF/CM/CU60D 0.99 0.96 0.93
FURNACE MULTIPLIERS- 4 TON (Continued)
Furnaces Coil
T.C. S.C. KW
