FORM 150.63-EG1
YCUL0016 - YCUL0040
SINGLE POINT POWER SUPPLY CONNECTIONS (See Fig. 1)
(One Field Provided Power Supply to the condensing unit. Field connections to Factory Provided Power Terminal Block (standard), Non-Fused Disconnect Switch
(optional) or Circuit Breaker (optional).)
OVER CURRENT PROTECTION,
UNIT VOLTAGE UNIT VOLTAGE CONTROL POWER
MCA
SEE NOTE B NFDISC Sw
NOTE A MIN MAX
MODELS w/o
CONTROL TRANS 115-1-60/50 15A 10A 15A 30 A / 240V
-17 200-1-60 15A 10A 15A 30 A / 240V
-28 230-1-60 15A 10A 15A 30 A / 240V
MODELS w/
-40 380-1-60 15A 10A 15A 30 A / 480V
CONTROL TRANS
-46 460-1-60 15A 10A 15A 30 A / 480V
-58 575-1-60 15A 10A 15A 30 A / 600V
Electrical Data
SINGLE POINT FIELD SUPPLIED WIRING SYSTEM #1 COMPRESSOR & FAN
MODEL
YCUL
VOLT HZ MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
COMPR. #1 COMPR. #2 COMPR. #3 FANS
TERMINAL
BLOCK (std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)
MIN
3
MAX
4
MIN MAX RLA LRA RLA LRA RLA LRA QTY
FLA
(EA)
0016
200 60 71 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 189 24.0 189 — — 2 8.2
230 60 70 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 189 24.0 189 — — 2 7.8
380 60 42 60 50 50 50 50 # 10 - # 1 # 14 - 2 # 14 - 2 14.4 112 14.4 112 — — 2 4.8
460 60 35 60 40 45 40 45 # 10 - # 1 # 14 - 2 # 14 - 2 12.0 99 12.0 99 — — 2 4.0
575 60 28 30 35 35 35 35 # 10 - # 1 # 14 - 2 # 14 - 2 9.6 74 9.6 74 — — 2 3.1
0026
200 60 92 100 100 110 100 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 33.2 278 33.2 278 — — 2 8.2
230 60 91 100 100 110 100 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 33.2 278 33.2 278 — — 2 7.8
380 60 55 60 60 70 60 70 # 10 - # 1 # 14 - 2 # 14 - 2 19.9 151 19.9 151 — — 2 4.8
460 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 2 # 14 - 2 16.6 127 16.6 127 — — 2 4.0
575 60 37 60 40 45 40 45 # 10 - # 1 # 14 - 2 # 14 - 2 13.3 100 13.3 100 — — 2 3.1
0030
200 60 107 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 8.2
230 60 106 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 7.8
380 60 64 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 — — 2 4.8
460 60 53 60 60 70 60 70 # 10 - # 1 # 14 - 2 # 14 - 2 19.9 167 19.9 167 — — 2 4.0
575 60 43 60 50 50 50 50 # 10 - # 1 # 14 - 2 # 14 - 2 16.0 125 16.0 125 — — 2 3.1
0036
200 60 124 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 47.8 425 47.8 425 — — 2 8.2
230 60 124 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 90 90 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.7 239 28.7 239 — —- 2 4.8
460 60 62 100 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.9 198 23.9 198 — — 2 4.0
575 60 50 60 60 60 60 60 # 10 - # 1 # 14 - 2 # 14 - 2 19.1 148 19.1 148 — — 2 3.1
0040
200 60 147 200 175 175 175 175 # 10 - 3/0 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 8.2
230 60 146 200 175 175 175 175 # 10 - 3/0 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 7.8
380 60 88 100 100 110 100 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 24.0 195 2 4.8
460 60 73 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 167 19.9 167 19.9 167 2 4.0
575 60 59 100 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 16.0 125 16.0 125 16.0 125 2 3.1
VOLTAGE RANGE
VOLTAGE CODE UNIT POWER MIN. MAX.
-17 200-3-60 180 220
-28 230-3-60 207 253
-40 380/415-3-60 342 440
-46 460-3-60 414 506
-58 575-3-60 517 633
A. Minimum #14 AWG, 75°C, Copper Recommended
B. Minimum and Maximum Over Current Protection, Dual Element Fuse or Circuit Breaker
