Maintenance and
Disassembly
Page 29
2. Disassembly
2.1 Indoor unit
2.1.1 Ceiling&Floor
1. Front Panel
Procedure Illustration
1) Remove the 2 screws of return air
grille subassembly and release the 2
hooks. (see CJ_CF_001)
2) Release the 2 hooks for each filter,
and then pull up the filter. (see
CJ_CF_002)
CJ_CF_001
CJ_CF_002
Note: This section is for reference only. Actual unit appearance may vary.
