Maintenance and
Disassembly
Page 31
3. Fan motor and fan
Procedure Illustration
1) Remove the fix screw of supporting
board. (see CJ_CF_005)
2) Remove the screws of fan motor
support and then remove the screw of
ground wire. (see CJ_CF_006)
CJ_CF_005
CJ_CF_006
Note: This section is for reference only. Actual unit appearance may vary.
