York YHJD18 User Manual

397855-YTG-G-0509
24 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
Continued on next page.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. YHJD42S41S1
INDOOR COIL MODEL NO. FC/MC/PC48
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1200 1400 1600
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 39.7 42.2 42.3 46.6 50.3 41.4 43.0 43.0 47.1 51.6 43.2 43.9 43.7 47.7 52.9
S.C. 39.7 37.8 32.1 32.0 25.7 41.4 41.1 34.2 33.9 27.1 43.2 43.9 36.3 35.8 28.4
KW 2.4 2.4 2.5 2.5 2.4 2.4 2.4 2.5 2.5 2.4 2.5 2.5 2.4 2.5 2.5
75
T.C. 38.3 40.2 40.3 44.3 48.1 39.9 41.0 41.0 44.9 49.1 41.6 41.9 41.7 45.6 50.2
S.C. 38.3 36.9 31.2 31.0 24.8 39.9 39.9 33.3 33.0 26.1 41.6 41.9 35.4 34.9 27.3
KW 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7 2.7
85
T.C. 36.9 38.2 38.2 41.9 45.8 38.4 39.0 39.0 42.7 46.7 40.0 39.9 39.7 43.5 47.5
S.C. 36.9 36.0 30.2 30.0 23.9 38.4 38.6 32.3 32.0 25.1 40.0 39.9 34.5 34.1 26.2
KW 2.9 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
95
T.C. 35.4 36.1 36.2 39.6 43.5 36.9 37.0 36.9 40.5 44.2 38.4 37.9 37.7 41.4 44.9
S.C. 35.4 35.1 29.2 29.0 23.0 36.9 37.0 31.4 31.1 24.1 38.4 37.9 33.5 33.2 25.1
KW 3.2 3.2 3.2 3.2 3.3 3.2 3.2 3.2 3.2 3.3 3.2 3.2 3.2 3.3 3.3
105
T.C. 33.2 33.7 33.4 36.7 40.2 34.5 34.6 34.1 37.4 40.8 35.9 35.5 34.8 38.1 41.4
S.C. 33.2 33.4 28.0 27.8 21.7 34.5 34.6 30.1 29.8 22.8 35.9 35.5 32.3 31.9 23.8
KW 3.6 3.6 3.6 3.6 3.7 3.6 3.6 3.6 3.6 3.7 3.6 3.6 3.6 3.7 3.7
115
T.C. 31.1 31.3 30.6 33.8 37.1 32.2 32.3 31.3 34.4 37.5 33.4 33.2 32.0 34.9 37.9
S.C. 31.1 31.3 26.8 26.6 20.4 32.2 32.3 28.9 28.6 21.5 33.4 33.2 31.0 30.6 22.6
KW 4.0 4.0 4.0 4.0 4.1 4.0 4.0 4.0 4.0 4.1 4.0 4.0 4.0 4.0 4.1
125
T.C. 28.9 28.9 27.9 31.0 33.9 29.9 29.9 28.5 31.4 34.2 30.9 30.9 29.2 31.7 34.5
S.C. 28.9 28.9 25.5 25.4 19.1 29.9 29.9 27.7 27.4 20.2 30.9 30.9 29.2 29.4 21.3
KW 4.5 4.4 4.4 4.4 4.5 4.4 4.4 4.4 4.4 4.5 4.4 4.4 4.4 4.4 4.5
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handlers Coils T.C. S.C. KW
– FC/MC/PC60 0.99 0.99 1.00
– HC42 1.00 0.99 1.00
– HC60 0.99 0.99 1.00
– HD60 1.01 1.00 1.00
AHX42 – 1.01 1.07 0.95
AHX48 – 1.02 1.09 0.96
AV/SV*48 – 1.01 1.06 0.96
F4FP045 – 0.99 1.00 1.00
F5FP048 – 1.02 1.04 1.00
F6FP042 – 1.01 1.08 0.97
F6FP048 – 1.02 1.07 0.96
AHP/SHP48 – 1.00 1.00 1.00
MA14D FC/MC/PC48D 1.00 1.00 1.00
MA16C FC/MC/PC48C 1.00 1.00 1.00
MV16C FC/MC/PC48C 1.02 1.02 1.00
MV20D FC/MC/PC48D 1.02 1.02 1.00
MA14D FC/MC/PC60D 0.99 0.99 1.00
MA16C FC/MC/PC60C 0.99 0.99 1.00
MV20D FC/MC/PC60D 1.01 1.01 1.00
