York YHJD18 User Manual

397855-YTG-G-0509
6 Johnson Controls Unitary Products
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL
FURNACE**
COIL
MODEL
COOLING
CFM RANGE
(Min.-max.)
W
RATED
CFM
NET MBH
SEER
1
EER
TOTAL SENS.
YHJD18S41S1
450 - 750 14,17 FC/MC/PC18 600 17.0 12.6 13.00 11.00
450 - 750 14,17 FC/MC/PC24 600 17.0 12.9 13.50 11.00
450 - 750 14 HC18 600 17.0 12.6 13.00 11.00
450 - 750 14 HC30 600 17.0 12.8 13.00 11.00
450 - 750 14 HD24 600 17.0 13.0 13.50 11.00
YHJD24S41S1
600 - 1000 14 FC/MC/PC32 800 23.0 17.5 13.00 11.00
600 - 1000 17,21 FC/MC/PC35 800 23.0 17.5 13.00 11.00
600 - 1000 14 HC30 800 23.0 17.2 13.00 11.00
600 - 1000 17 HC36 800 23.0 17.5 13.00 11.00
600 - 1000 14,17 HD36 800 23.0 16.4 13.00 11.00
YHJD30S41S1
800 - 1200 14 FC/MC/PC37 1000 29.0 23.4 13.00 11.00
800 - 1200 17,21 FC/MC/PC43 1000 29.0 23.4 13.00 11.00
800 - 1200 21 HC42 1000 29.0 23.4 13.00 11.00
800 - 1200 21,24 HD48 1000 29.0 23.4 13.00 11.00
YHJD36S41S1
1000 - 1400 14 FC/MC/PC37 1200 35.0 26.6 13.00 11.00
1000 - 1400 17,21 FC/MC/PC43 1200 35.0 26.8 13.00 11.00
1000 - 1400 21,24 FC/MC/PC48 1200 35.0 27.0 13.00 11.00
1000 - 1400 21 HC42 1200 35.0 26.8 13.00 11.00
1000 - 1400 21,24 HD48 1200 35.0 26.8 13.00 11.00
YHJD42S41S1
1200 - 1600 21,24 FC/MC/PC48 1400 41.5 31.4 13.00 11.00
1200 - 1600 21,24 FC/MC/PC60 1400 41.0 31.2 13.00 11.00
1200 - 1600 21 HC42 1400 41.0 31.2 13.00 11.00
1200 - 1600 24 HC60 1400 41.0 31.2 13.00 11.00
1200 - 1600 21,24 HD60 1400 41.5 31.4 13.00 11.00
YHJD48S41S1
1400 - 1800 24 HC60 1600 47.0 35.6 13.00 11.00
1400 - 1800 21,24 HD60 1600 47.0 35.4 13.00 11.00
1400 - 1800 21,24 MC62 1600 47.0 35.6 13.00 11.00
YHJD60S41S1 1600 - 2000 21,24 MC62 1800 54.0 42.5 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.

York YHJD18 Specifications

General

Brand	York
Model	YHJD18
Category	Heat Pump
Language	English

Summary

York Technical Guide Overview

Product Description

Details the 13 SEER Series unit as the outdoor component of a versatile climate system.

Key Unit Features

Highlights benefits like quality condenser coils, protected compressor, durable finish, and low operating sound.

Available Unit Accessories

Start Assist Kit

May be required for specific models to provide starting torque.

Blower Time Delay

Improves efficiency by maintaining blower operation after cooling thermostat is satisfied.

Hard Start Kits

Provides required starting torque for use with Thermal Expansion Valve Kits.

Low Temperature Cutout

Prevents heat pump operation below -10°F ambient temperature.

Compressor Blanket

Designed to further reduce the normal operating sound of the unit.

Add-on Fossil Fuel Control

Interface controls for use with gas, oil furnaces and heat pump systems.

Thermal Expansion Valve Kit

TXV kit used to improve system performance and efficiency.

Typical Unit Installation Guidelines

Outdoor Unit Clearance Requirements

Specifies minimum clearances for overhead, service access, and perimeter.

Field Wiring Diagrams and Instructions

Thermostat and Indoor Unit Wiring

Details low-voltage wiring connections for thermostat to indoor unit.

Outdoor Unit Power and Control Wiring

Explains power wiring and control wiring for the outdoor unit.
