Johnson Controls Unitary Products 3
System Charge for Various Matched Systems
Outdoor Unit
YHJD18
S41S7
YHJD24
S41S7
YHJD30
S41S7
YHJD36
S41S7
YHJD42
S41S7
YHJD48
S41S7
YHJD60
S41S7
Required Orifice or TXV
1,2
.051/4F1 .059/4N1 .063/4G1 .071/4H1 .075/4J1 4K1 4K1
Indoor Unit
3,4,5
Additional Charge, Oz
AHE22B .051 / TXV + 0
– – – – – –
AHE24B .051 / TXV + 0 .059 / TXV + 0
– – – – –
AHE30B .051 / TXV + 0 .059 / TXV + 0 .063 / TXV + 0
– – – –
AHE36C
– –
.063 / TXV + 5 .071 / TXV + 0
– – –
AHE42D
– – –
.071 / TXV + 5 .075 / TXV + 0
– –
AHE48D
– – – –
.075 / TXV + 8 TXV + 0
–
AHE60D
– – – – –
TXV + 48 TXV + 0
AHV24B .051 / TXV + 0 .059 / TXV + 0
– – – – –
AHV30B .051 / TXV + 0 .059 / TXV + 0 .063 / TXV + 0
– – – –
AHV36C
–
.059 / TXV + 12 .063 / TXV + 5 .071 / TXV + 0
– – –
AHV42D
– – –
.071 / TXV + 5 .075 / TXV + 0
– –
AHV48D
– – – –
.075 / TXV + 8 TXV + 0
–
AHV60D
– – – – –
TXV + 48 TXV + 0
FC/MC/PC24 .051 / TXV + 0
– – – – – –
FC/MC/PC30 .051 / TXV + 0
– – – – – –
FC/MC/PC32 .051 / TXV + 0 .059 / TXV + 0 .063 / TXV + 0
– – – –
FC/MC/PC35 .051 / TXV + 0 .059 / TXV + 0 .063 / TXV + 0
– – – –
FC/MC/PC37
–
.059 / TXV + 12 .063 / TXV + 5 .071 / TXV + 0
– – –
FC/MC/PC43
–
.059 / TXV + 12 .063 / TXV + 5 .071 / TXV + 0
– – –
FC/MC/PC48
– – –
.071 / TXV + 5 .075 / TXV + 0
– –
FC/MC/PC60
– – – –
.075 / TXV + 8 TXV + 0
–
FC/MC62
– – – – –
TXV + 48 TXV + 0
FC64
– – – – – –
TXV + 23
Some of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. For approved
coil only matches, please see the “COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils” table.
FOOTNOTES:
1.
For applications requiring a TXV use S1-1TVM*** series kit.
2.
Approved orifice(s) shipped with outdoor unit.
3.
Systems matched with furnaces or air handlers not equipped with blower-off delays may require blower Time Delay Kit S1-2FD06700224.
4.
PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
5.
Refer to Cooling and Heating Performance Data tables for actual performance for specified system matches.
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the outdoor unit, the smallest matched indoor unit, and 15 feet of interconnecting line
tubing.
2. Verify the TXV or orifice and additional charge required for specific matched indoor unit in the system using the above table.
3. Add additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical Data Table.
4. For indoor matches requiring additional charge, the refrigerant needs to be weighed in for specific matched indoor unit and actual lineset length.
5. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + charge adder for matched indoor unit +
charge adder for actual lineset length.
571209-YTG-F-0615
