HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO YHJD60S41S7
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
AIR TEMP.
ENTERING
INDOOR
COIL
ID CFM
1600 1800 2000
MBH COP KW MBH COP KW MBH COP KW
60
60 72.1 3.76 5.02 71.1 3.77 4.85 70.1 3.79 4.68
70 70.9 3.40 5.52 70.6 3.44 5.34 70.3 3.49 5.17
80 69.8 3.09 6.02 70.2 3.16 5.84 70.5 3.23 5.66
47
60 62.7 3.68 4.39 62.4 3.69 4.28 62.1 3.71 4.16
70 61.1 3.30 4.82 61.1 3.52 4.42 61.1 3.76 4.02
80 59.6 2.98 5.26 59.9 3.35 4.56 60.1 3.82 3.87
40
60 55.6 3.52 4.04 55.9 3.55 3.95 56.2 3.58 3.86
70 54.3 3.14 4.47 54.5 3.17 4.36 54.8 3.21 4.26
80 52.9 2.82 4.90 53.1 2.85 4.78 53.3 2.89 4.66
30
60 45.3 3.16 3.60 45.7 3.19 3.53 46.1 3.21 3.46
70 43.9 2.85 3.91 44.3 2.87 3.86 44.8 2.89 3.81
80 42.4 2.58 4.22 43.0 2.59 4.19 43.5 2.60 4.15
17
60 38.0 2.83 3.33 38.5 2.85 3.30 39.1 2.86 3.26
70 35.5 2.48 3.60 36.5 2.52 3.58 37.5 2.55 3.56
80 33.0 2.16 3.87 34.4 2.23 3.86 35.9 2.28 3.86
10
60 32.3 2.55 3.11 32.8 2.57 3.07 33.3 2.60 3.02
70 31.3 2.27 3.44 31.5 2.28 3.38 31.8 2.28 3.33
80 30.3 2.04 3.76 30.2 2.03 3.70 30.2 2.02 3.64
NOTE: ALL CAPACITIES ARE NET, WITH INDOOR FAN HEAT ALREADY DEDUCTED. KW VALUES ARE FOR THE SYSTEM (OUT-
DOOR + INDOOR).
Yellow shaded cells are AHRI High Heating conditions. Orange shaded cells are AHRI Low Heating conditions.
Multipliers for determining the performance with other indoor sections.
Some of the combinations shown in these multiplier tables are not valid for use in the U.S.A. Please see the Capacity
Tables in the front of this Technical Guide for US matches, and verify matchups in the online AHRI directory at
www.ahridirectory.org before sale. The matches shown at the end of this Technical Guide are for use in Canda Only.
Air Handlers Coils MBH COP KW
–
FC/MC62D 0.93 1.03 1.04
–
FC64D 0.93 1.03 1.04
AHE60D
–
0.93 1.07 1.00
AHV60D
–
0.93 1.03 1.04
MV20D FC/MC62D 0.93 1.06 1.01
MV20D FC64D 0.93 1.09 0.98
MX20DN21 FC/MC62D 0.93 1.07 1.00
MX20DN21 FC64D 0.93 1.10 0.97
Furnaces Coils MBH COP KW
T*(8,L)V*C20
FC/MC62D 0.93 1.02 1.05
T*(8,L)V*C20
FC64D 0.93 1.09 0.99
T*9V*C20 FC/MC62D 0.93 1.02 1.06
T*9V*C20 FC64D 0.93 1.05 1.02
T*9V*D20 FC/MC62D 0.93 1.02 1.05
T*9V*D20 FC64D 0.93 1.06 1.02
TM8X100C20MP11 FC/MC62D 0.93 1.03 1.04
TM8X100C20MP11 FC64D 0.93 1.06 1.02
Furnaces Coils MBH COP KW
TM8X120C20MP11 FC/MC62D 0.93 1.03 1.04
TM8X120C20MP11 FC64D 0.93 1.06 1.02
TM9E100C20MP11 FC/MC62D 0.93 1.01 1.06
TM9E100C20MP11 FC64D 0.93 1.04 1.03
TM9E120D20MP11 FC/MC62D 0.93 1.01 1.06
TM9E120D20MP11 FC64D 0.93 1.03 1.04
TMLX100C20MP11 FC/MC62D 0.93 1.03 1.04
TMLX100C20MP11 FC64D 0.93 1.06 1.02
TMLX120C20MP11 FC/MC62D 0.93 1.03 1.04
TMLX120C20MP11 FC64D 0.93 1.06 1.02
Y*(8,L)C*C20
FC/MC62D 0.93 1.02 1.05
Y*(8,L)C*C20
FC64D 0.93 1.09 0.99
Y*9C*C20 FC/MC62D 0.93 1.02 1.06
Y*9C*C20 FC64D 0.93 1.05 1.02
Y*9C*D20 FC/MC62D 0.93 1.02 1.05
Y*9C*D20 FC64D 0.93 1.06 1.02
