FORM 150.72-EG6 (516)
JOHNSON CONTROLS
23
REFRIGERANT R-410A
YLAA
REFRIGERANT R-410A
YLAA
STANDARD EFFICIENCY UNITS HIGH EFFICIENCY UNITS
0070SE 0080SE 0089SE 0100SE 0120SE 0136SE 0155SE 0170SE 0058HE 0065HE 0081HE 0092HE 0101HE 0125HE 0142HE 0156HE 0175HE
NOMINAL RATINGS NOMINAL RATINGS
TONS 71.0 77.8 81.8 95.6 118.1 126.1 143.0 167.4 TONS 57.0 62.3 78.8 85.7 98.3 116.0 129.5 144.5 172.5
KW 77.5 86.3 93.0 111.5 134.6 142.6 165.0 192.1 KW 64.4 71.9 91.0 83.6 106.1 122.0 138.9 153.0 194.2
EER 10.4 10.0 9.8 9.6 9.8 9.6 9.6 9.6 EER 10.6 10.4 10.4 11.0 10.1 10.3 10.2 10.2 9.8
IPLV 16.1 15.6 15.7 14.5 15.0 15.7 15.6 15.6 IPLV 15.6 15.6 16.1 16.1 15.7 15.7 15.9 15.5 15.6
GENERAL UNIT DATA GENERAL UNIT DATA
Length 116.1 116.1 116.1 142.7 142.7 187.7 187.7 232.7 Length 100.2 100.2 100.2 142.7 142.7 187.7 187.7 232.7 232.7
Width 88 88 88 88 88 88 88 88 Width 88.0 88.0 88.0 88 88 88 88 88 88
Height 94.2 94.2 94.2 94.2 94 94.2 94.2 94.2 Height 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2
Number of Refrigerant
Circuits
2 2 2 2 2 2 2 2
Number of Refrigerant
Circuits
2 2 2 2 2 2 2 2 2
REFRIGERANT CHARGE, OPERATING REFRIGERANT CHARGE, OPERATING
R-410A, Circuit 1 / Circuit 2, lbs 43/43 47/44 57/57 55/58 54/62 75/71 75/70 90/87
R-410A, Circuit 1 / Circuit 2,
lbs
43/43 43/43 44/44 59/55 45/65 75/71 83/73 90/82 94/92
Oil Charge, Circuit 1 / Circuit 2,
gallons
2.58/2.58 3.28/2.58 3.28/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33 4.99/4.99
Oil Charge, Circuit 1 / Circuit
2, gallons
2.58/2.58 2.89/2.58 2.58/2.58 2.76/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33 4.99/4.99
Shipping Weight 3578 3898 4168 4791 5183 6148 6414 7734 Shipping Weight 3508 3704 4061 4718 4953 5869 6259 7344 7882
Operating Weight 3623 3954 4241 4864 5293 6232 6524 7818 Operating Weight 3552 3748 4145 4791 5026 5942 6369 7428 8001
COMPRESSORS, SCROLL TYPE COMPRESSORS, SCROLL TYPE
Compressors per circuit 3/3 3/3 3/3 3/2 2/2 3/3 3/2 3/3 Compressors per circuit 2/2 3/2 3/3 3/3 3/2 2/2 3/3 3/2 3/3
Compressors per unit 6 6 6 5 4 6 5 6 Compressors per unit 4 5 6 6 5 4 6 5 6
NOMINAL TONS PER COMPRESSOR NOMINAL TONS PER COMPRESSOR
Circuit 1 13 15 15 15 32 32 32 32 Circuit 1 15 13 15 15 15 32 32 32 32
Circuit 2 13 13 15 32 32 15 32 32 Circuit 2 15 15 13 15 32 32 15 32 32
CONDENSER CONDENSER
Total Face Area ft
2
106.9 106.9 106.9 133.6 160.3 213.8 213.8 267.2 Total Face Area ft
2
106.9 106.9 106.9 160.3 160.3 213.8 213.8 267.2 267.2
Number of Rows 1 1 1 1 1 1 1 1 Number of Rows 1 1 1 1 1 1 1 1 1
Fins per Inch 20 20 20 20 20 20 20 20 Fins per Inch 20 20 20 20 20 20 20 20 20
CONDENSER FANS, LOW SOUND CONDENSER FANS, LOW SOUND
Number of Fans, Circuit 1/
Circuit 2
2/2 2/2 2/2 3/2 3/3 4/4 4/4 5/5
Number of Fans, Circuit 1/
Circuit 2
2/2 2/2 2/2 3/3 4/2 4/4 5/3 6/4 5/5
Fan hp 2 2 2 2 2 2 2 2 Fan hp 2 2 2 2 2 2 2 2 2
Fan RPM 1160 1160 1160 1160 1160 1160 1160 1160 Fan RPM 1160 1160 1160 1160 1160 1160 1160 1160 1160
Total Chiller CFM 62400 62400 62400 78000 93600 124800 124800 156000 Total Chiller CFM 62400 62400 62400 93600 93600 124800 124800 156000 156000
EVAPORATOR EVAPORATOR
Water Volume, Gallons 5.4 6.7 8.8 8.8 13.2 10.0 13.2 10.0 Water Volume, Gallons 5.4 5.4 10 8.8 8.8 8.8 13.2 10.0 14.3
Maximum Water Side
Pressure, Psig
150 150 150 150 150 150 150 150
Maximum Water Side
Pressure, PSIG
150 150 150 150 150 150 150 150 150
Maximum Refrigerant Side
Pressure, Psig
450 450 450 450 450 450 450 450
Maximum Refrigerant Side
Pressure, PSIG
450 450 450 450 450 450 450 450 450
Minimum Chiller Water Flow
Rate, Gpm
60 100 140 100 150 150 150 150
Minimum Chiller Water Flow
Rate, GPM
60 60 150 100 100 100 150 150 150
Maximum Chiller Water Flow
Rate, Gpm
285 355 385 385 625 625 625 625
Maximum Chiller Water Flow
Rate, GPM
285 285 625 385 385 385 625 625 625
Water Connections Size,
Inches
3 3 3 3 3 4* 4* 4*
Water Connections Size,
Inches
3 3 3 3 3 4* 4* 4* 4*
* Side extension kit (standard), evaporator nozzle remains 3”.
* Side extension kit (standard), evaporator nozzle remains 3”.
Physical Data and Nominal Ratings (Cont'd)
