York YLAA User Manual

FORM 150.72-EG6 (516)
JOHNSON CONTROLS
43
YLAA
GLOBAL MARKET
SINGLE POINT
SUPPLY
TERMINAL
BLOCK
MOLDED CASE
SWITCH SINGLE
POINT SUPPLY
MOLDED CASE
CIRCUIT BREAKER
SINGLE POINT SUPPLY
VOLTS HZ
INSTALLED
LUG
INSTALLED
LUG
ALTERNATE
LUG
INSTALLED
LUG
ALTERNATE
LUG
0100/0101
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
460 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (1) 6 - 350 - (1) 6 - 350 -
0120/0130/0125
208 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
400/460 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
0135/0141
208 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (1) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
400/460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
0136/0142
208 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
230 60
380 60 (2) # 6 - 500 (3) 2/0 - 400 (2) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
400/460 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
0150/0155/0158/
0156
208 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
230 60 (3) 2/0 - 400 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500
380 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
400/460 60 (2) # 6 - 500 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
0170/0175
208 60 (4) 4/0 - 500 (4) 4/0 - 500 - (3) 2/0 - 400 (2) 250 - 500
230 60 (4) 4/0 - 500 (4) 4/0 - 500 - (3) 2/0 - 400 (2) 250 - 500
380 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 250 - 500 (3) 2/0 - 400
460 60 (2) # 6 - 500 (2) 250 - 500 (3) 2/0 - 400 (2) 3/0 - 250 (1) 250 - 500
575 60 (1) # 6 - 500 (2) 3/0 - 250 (1) 250 - 500 (2) 3/0 - 250 (1) 250 - 500
Wiring Lugs (Cont'd)
NOTE:Alternatelugsareprovidedinthepanelforeldelectriciansandcontractors,shouldtherebeaneedforotherlugarrangementsthatthe
installed lugs on the non-fused disconnect switch and circuit breaker panels.
