York YLAA User Manual

FORM 150.72-EG6 (516)
JOHNSON CONTROLS
47
YLAA VOLT HZ MCA
MIN
N/F
DISC
SW
MIN
DUAL
ELEM
FUSE
& CB
MAX
DUAL
ELEM
FUSE
& CB
SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA
101
208 60 483 600 500 500 106.2 523 106.2 523 4 7.6 44
230 60 478 600 500 500 106.2 578 106.2 578 4 7.4 37
380 60 278 400 300 300 64.3 355 64.3 355 4 4.5 23.1
460 60 235 250 250 250 53.1 290 53.1 290 4 4 19
575 60 181 200 200 200 42.5 255 42.5 255 4 2.9 15.3
120
208 60 522 600 600 600 106.2 523 106.2 523 3 7.6 44
230 60 517 600 600 600 106.2 578 106.2 578 3 7.4 37
380 60 313 400 350 350 64.3 355 64.3 355 3 4.5 23.1
460 60 261 400 300 300 53.1 290 53.1 290 3 4 19
575 60 202 250 225 225 42.5 255 42.5 255 3 2.9 15.3
125
208 60 537 600 600 600 106.2 523 106.2 523 4 7.6 44
230 60 532 600 600 600 106.2 578 106.2 578 4 7.4 37
380 60 322 400 350 350 64.3 355 64.3 355 4 4.5 23.1
460 60 269 400 300 300 53.1 290 53.1 290 4 4 19
575 60 204 250 225 225 42.5 255 42.5 255 4 2.9 15.3
136
208 60 579 800 600 600 57.7 284 57.7 284 57.7 284 4 7.6 44
230 60 577 800 600 600 57.7 330 57.7 330 57.7 330 4 7.4 37
380 60 338 400 400 400 30.9 192 30.9 192 30.9 192 4 4.5 23.1
460 60 285 400 300 300 26.9 180 26.9 180 26.9 180 4 4 19
575 60 226 250 250 250 21.5 132 21.5 132 21.5 132 4 2.9 15.3
142
208 60 579 800 600 600 57.7 284 57.7 284 57.7 284 3 7.6 44
230 60 577 800 600 600 57.7 330 57.7 330 57.7 330 3 7.4 37
380 60 338 400 400 400 30.9 192 30.9 192 30.9 192 3 4.5 23.1
460 60 285 400 300 300 26.9 180 26.9 180 26.9 180 3 4 19
575 60 226 250 250 250 21.5 132 21.5 132 21.5 132 3 2.9 15.3
155
208 60 618 800 700 700 106.2 523 106.2 523 4 7.6 44
230 60 617 800 700 700 106.2 578 106.2 578 4 7.4 37
380 60 374 400 400 400 64.3 355 64.3 355 4 4.5 23.1
460 60 311 400 350 350 53.1 290 53.1 290 4 4 19
575 60 246 400 300 300 42.5 255 42.5 255 4 2.9 15.3
156
208 60 634 800 700 700 106.2 523 106.2 523 4 7.6 44
230 60 632 800 700 700 106.2 578 106.2 578 4 7.4 37
380 60 383 400 400 400 64.3 355 64.3 355 4 4.5 23.1
460 60 319 400 350 350 53.1 290 53.1 290 4 4 19
575 60 252 400 300 300 42.5 255 42.5 255 4 2.9 15.3
170
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
175
208 60 740 800 800 800 106.2 523 106.2 523 106.2 523 5 7.6 44
230 60 738 800 800 800 106.2 578 106.2 578 106.2 578 5 7.4 37
380 60 447 600 500 500 64.3 355 64.3 355 64.3 355 5 4.5 23.1
460 60 372 400 400 400 53.1 290 53.1 290 53.1 290 5 4 19
575 60 295 400 350 350 42.5 255 42.5 255 42.5 255 5 2.9 15.3
Electrical Data Without Pumps (Cont'd)
NOTES:
1. Reference PIN 59 for pump models.
2. Use this table along with Pump Electrical Data on page 47 to determine electrical data of the unit plus the pump.
3. Does not include the Control Transformer on page 41)
