FORM NO.:6U6K-B01E-NB-EN
JOHNSON CONTROLS
84
TWO INCH DEFLECTION SPRING ISOLATOR CROSS-
REFERENCE
Outline Drawing – Type LAT Isolators
LAT-160
LAT-180
LAT-200
LAT-230
LAT-250
LAT-300
160
180
200
230
250
300
1568
1764
1960
2254
2450
2940
3.20
3.60
4.00
4.60
5.00
6.00
L CW DH S1 S2
196 95 170 170 13.5 M10X30 M20X60
MODEL
LOAD
（kg）
LOAD
（N）
DEFLECTION
（mm）
45～50
VERTICAL
RIGIDITY
(kg/mm)
OUTER SIZE( ±2mm)
Technical Data - Type LAT Isolators
SECTION 5 – TECHNICAL DATA
