Specifications
Power @ min. impedance (Watts)
200
Minimum Impedance (Ohms)
2
Burst Power - 2 cycle
250 Watts
Speaker Configuration - LF (Size / Power)
xm200: 1x 15 inch; xm200T:2x 10 inch
Speaker Configuration - HF (Size / Power)
Piezo Tweeter / 30 Watts
Hum and Noise (dB)
-90dB Unweighted / -94 Aweighted
Input Channels
1
Channel 1 - inputs
2 (-6 dB and 0 dB)
Channel 1 - controls
Volume, Bass, Low Mid, Hi Mid, Treble and Scoop
Channel 1 - switches
Mute, Limiter, Line / D.I. Output Select
Input Sensitivity (mV)
<25
Line Out (type / configuration)
Balanced XLR / Front
Line Out Sensitivity (Vrms)
<1
Effects Loop / Location
Yes / Front
Effects Return Sensitivity (Vrms)
<1
LED Indicators
blue Power
Protection
Thermal, Short Ciruit
Limiter / Switchable
Yes / Yes
External speaker output / location
Rear
Headphone Jack
Yes
Dimensions (DWH, inches)
xm200: 14 x 21 x 23.5; xm200T:14x21x21
Dimensions (DWH, cm)
xm200: 37 x 54 x 60; xm200T:
Weight (lbs / kg)
57 / 26
