B. Burner crown
C. Ignition candle
D. Thermocouple
IGNITION OF THE BURNER
Always light the burner before you put
on the cookware.
WARNING! Be very careful when you
use open fire in the kitchen
environment. The manufacturer
declines any responsibility in case of
the flame misuse.
1. Push the control knob down and turn it
counterclockwise to the maximum gas supply
position ( ).
2. Keep the control knob pushed for equal or less
than 10 seconds. This lets the thermocouple
warm up. If not, the gas supply is interrupted.
3. Adjust the flame after it is regular.
If after some tries the burner does not
light, check if the crown and its cap
are in correct positions.
WARNING! Do not keep the control
knob pushed for more than 15
seconds. If the burner does not light
after 15 seconds, release the control
knob, turn it into off position and try to
light the burner again after minimum 1
minute.
CAUTION! In the absence of
electricity you can ignite the burner
without electrical device; in this case
approach the burner with a flame, turn
the control knob counter-clockwise to
maximum gas supply position and
push it down. Keep the control knob
pushed for equal or less than 10
seconds to let the thermocouple warm
up.
If the burner accidentally goes out,
turn the control knob to the off position
and try to light the burner again after
minimum 1 minute.
The spark generator can start
automatically when you switch on the
mains, after installation or a power cut.
It is normal.
The hob is supplied with the
progressive valves. They make the
flame regulation more precise.
TURNING THE BURNER OFF
To put the flame out, turn the knob to the off
position .
WARNING! Always turn the flame
down or switch it off before you
remove the pans from the burner.
HINTS AND TIPS
WARNING! Refer to Safety chapters.
COOKWARE
CAUTION! Do not use cast iron pans,
clay or earthenware pots, grill or
toaster plates. The stainless steel can
become tarnished if it is too much
heated.
WARNING! Do not put the same pan
on two burners.
WARNING! Do not put unstable or
damaged pots on the burner to
prevent spills and injuries.
CAUTION! Make sure that the
bottoms of pots do not stand too
close to the control knob, otherwise
the flame heats the control knob up.
CAUTION! Make sure that pot
handles are not above the front edge
of the cooktop.
CAUTION! Make sure that the pots
are placed centrally on the burner in
order to get the maximum stability and
a lower gas consumption.
12

Zanussi ZGNN640W Specifications

General

Hob type	Gas
Product color	White
Hob width size	60 cm
Top surface type	-
Appliance placement	Built-in
Cooking zone 2 type	Large
Cooking zone 3 type	Regular
Cooking zone 4 type	Simmer
Cooking zone 1 power	2000 W
Cooking zone 2 power	3000 W
Cooking zone 4 power	1000 W
Cooking zone 1 position	Left rear
Cooking zone 2 position	Left front
Cooking zone 3 position	Right rear
Cooking zone 4 position	Right front
Simmer cooking zone shape	Round
Large cooking zone diameter	100 mm
Number of gas cooking zones	4 zone(s)
Simmer cooking zone diameter	54 mm
Regular cooking zone diameter	70 mm
Number of electric cooking zones	0 zone(s)
Control type	Rotary
Built-in display	No
Control position	Top right
Electronic ignition	Yes
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Connected load (gas)	8000 W
Connected load (electric)	- W

Weight and Dimensions

Depth	510 mm
Width	594 mm
Cord length	1.1 m
Installation compartment depth	470 mm
Installation compartment width	550 mm
Installation compartment height	43 mm
