15 CREEP SPEED = Minimum Speed. This Parameter sets the minimum voltage
applied to the motor at the start of travel.
16 SEAT MICRO DELAY = Delay time after Seat Microswitch has opened.
17 HYDRO TIME = Operating time for Steering Contactor after controller has oper-
ated. This Parameter is configured in the SET OPTION Menu.
18 BACKING TIME = Operation time of the BACKING Function.
19 BACKING SPEED = Drive Motor Speed during the BACKING function. The chart
on Page 23 shows the different values to which the parameters may be adjusted.
5.3 TABLE OF ADJUSTMENTS
The following Table shows the different values that the SEM2 Parameters may be
adjusted to. A suitable acceleration performance assumes: FIELD CURR. NOM is set
to level 5, and MAX SPEED (Fwd or Rev) is set to level 9.
PARAMETERS
(24/48V VERSION)
PROGRAMMED LEVEL
UNIT0123456789
ACC. DELAY sec. 0.3 0.6 0.9 1.3 1.6 1.9 2.3 2.5 2.8 3.1
DEC. DELAY * 0123456789
RELEASE BRAKING * 0 1 2 3 4 5 6 7 8 9
PEDAL BRAKNG * 0 1 2 3 4 5 6 7 8 9
INVERS BRAKING * 0123456789
TRACTION I MAX %IMax 82 84 85 87 89 91 93 95 97 100
ARMA CUR. NOM. (ACN) %IMax 32 35 38 41 44 47 50 53 56 58
FIELD CURR. NOM. (FCN) A 12 13 14 15 16 17 18 19 20 21
MAX SPEED FORW. %FCN 100 82 65 55 50 45 40 35 32 30
MAX. SPEED BACK. %FCN 100 82 65 55 50 45 40 35 32 30
WEAK DROP OUT %ACN 35 40 45 50 55 60 65 70 75 80
CUTBACK SPEED 1 %ACC20253040455055607080
CUTBACK SPEED 2 %ACC20253040455055607080
CUTBACK SPEED 3 %ACC20253040455055607080
CREEP SPEED %VBatt 3 5 7 9 11 13 15 17 19 21
SEAT MICRO DELAY sec. 0.5 0.7 0.9 1.1 1.4 1.6 1.8 2.0 2.2 2.5
HYDRO TIME sec. 0 0.5 1.0 1.6 2.2 2.7 3.2 3.8 4.4 5.0
BACKING TIME sec. 0.05 0.2 0.3 0.5 0.8 1.0 1.5 2.0 2.5 3.0
BACKING SPEED %VBatt. 32 40 45 52 58 65 72 78 85 90
*= If the current inclines to raise, then also the braking time raises in order to obtain a
smooth braking action. Therefore, the duration of the braking depends on the type of
motor and the operating conditions (laden, unladen, on plane, on gradient).
