Features & Controls – Touch Controls
16
www.zephyronline.com
Baffle Filter Clean Reminder
Aa set of baffle filters are fitted by the factory, these baffle filters are intended to filter out residue from
cooking. The filters need not be replaced on a regular basis but are required to be kept clean. The Baffle-
Filter Clean reminder function in the microprocessor will automatically indicate by a flashing when the
baffle filters need to be cleaned after every 30 hours of use. Filters can be cleaned by hand with non-
abrasive soap or in a dishwasher. Heavily soiled filters should also be soaked in grease cutting detergent
prior to cleaning.
Baffle Filter Clean Indicator
When flashes on the display, the baffle filters
needo be cleaned. This will occur after every 30
hours of use.
Reset the filter clean reminder timer after filters are
cleaned and re-installed. With hood off, press and
hold for approximately 5 seconds until on
display disappears . The filter clean reminder
function is now reset and a new 30 hours elapse
cycle is initiated.
Clean Filters
display < F > flashes
hold 5 sec. display from < F > to < >
To Reset
hold 5 sec. display from < A > to < >
To Disable
hold 5 sec.
To Enable
display < A > flashes
Clean Air Indicator
While Clean Air is active, the display will alternate
between , , , .
After 10 minutes of Clean Air operation, the blower
will power off and the 4 hour timer will reset.
If the blower speed is changed while the Clean Air
Function is in use, the cycle will be interrupted and
the timer will reset after.
Clean Air Function
Clean Air is a feature that turns on the blower on low speed every 4 hours for 10 minutes to remove stagnant
air in the kitchen. The Clean Air function is disabled by default and must be enabled by the user.
